Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > 1xN Cascade Optical Switch

1xN Cascade Optical Switch

Name: 1xN Cascade Optical Switch
Brand: Glsun
SKU: 172886462
Availability: InStock

Guilin Glsun Integrated Technology Co., Ltd

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Brand Name:

Glsun

Place of Origin:

China

Model Number:

SUN-FSW-A-B-C-D-E-F-G

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

ShenZhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name Glsun

Place of Origin China

Model Number SUN-FSW-A-B-C-D-E-F-G

SUN-FSW-1×N Cascade Optical Switch is an ideal component for OADM, OXC, system monitoring and protection. With compact package, this fiber optic switch can be easy to integrate into a high density optical communication system.

Features
·Wide Wavelength Range
·Low Crosstalk
·High Stability, High Reliability
·Epoxy-free on Optical Path

Applications
·R&D in Laboratory
·System Monitoring
·OADM
·OXC

Specification

Parameters	Unit	SUN-FSW-1×4	SUN-FSW-1×8		SUN-FSW-1×16
Wavelength Range	nm	850±40 / 1300±40		1260 ~ 1650
Test Wavelength	nm	850 / 1300		1310 / 1550
Insertion Loss(SM)	dB	Typ: 0.8 Max: 1.0	Typ: 1.4 Max: 1.6		Typ: 1.8 Max: 2.0
Insertion Loss(MM)		Typ: 1.0 Max: 1.2	Typ: 1.6 Max: 1.8		Typ: 2.0 Max: 2.2
Return Loss	dB	MM ≥ 30 SM ≥ 50
Crosstalk	dB	MM ≥ 35 SM ≥ 55
PDL	dB	≤ 0.15
WDL	dB	≤ 0.35
Repeatability	dB	≤ ±0.05
Power Supply	V	5.0 ± 5%
Durability	Cycles	≥ 10 Million
Switching Time	ms	≤8
Optical Power	mW	≤500
Operating Temperature	℃	-5 ~ +70
Storage Temperature	℃	-40 ~ +85
Relative Humidity	%	5 ~ 95
Dimension	mm	(L)130×(W)95×(H)15
