Automatic Lathe Turning Graphite Wear-resistant Graphite Box Processing Equipment S-500NCM

Max. Rotation Dia:   Φ530mm

Max. Turning Dia:   Φ460mm

Max. Dia Machining On The Tool Holder:   Φ280mm

Max. Turning Length:   500mm

Bar Capacity:   Φ52

Spindle Head Type:   A2--6

Max. Spindle Speed:   3500rpm

Worktable Dimensions:   270*500mm

X/Z Rapid Speed:   X--Axis:   24m/min | Z--Axis:   24m/min

Positioning Accuracy:   +-0.008/300mm

Repeatability:   +-0.005/300mm

Turret Type:   12T Servo Turret

External Diameter Tool Holder:   25*25mm

Dia. Of Tailstock Sleeve:   Φ80mm

Travel Of Tailstock Sleeve:   80mm

Taper Hole Of Tailstock Sleeve:   Morse 5#

Machine Tool Dimensions:   2650*1950*1800mm

Machine Tool Weight:   3700Kg

Torque:   Customizable configuration

Drilling Capacity:   Customizable configuration

Voltage:   380V

Frequency:   50/60 Hz

Phase Type:   3--Phase Electricity

Color:   Black

Usage/Application:   Graphite Processing|Carbon Fiber Processing|Ceramic Processing|Composite Material Processing

Can it be customized:   Supports customization

Guarantee:   One year warranty for the whole machine

Brand:   ShangshanJingji

The Automatic Lathe Turning Graphite is a highly specialized machine designed for precision machining of graphite materials, ensuring consistent results for complex parts and components. This lathe is particularly effective for creating components such as graphite boats, electrodes, and other intricate graphite parts used in various industrial applications. Leveraging advanced CNC technology, the machine offers automated turning capabilities that allow for the efficient and precise shaping of graphite materials, even with challenging geometries. With the ability to handle isostatic isotropic graphite, the lathe can deliver high-quality results for a wide range of projects, whether it involves the machining of wear-resistant graphite box components or fine-tuned parts with minimal material waste. The combination of automatic lathe turning and CNC control ensures that manufacturers can achieve optimal precision with minimal intervention, improving production efficiency and consistency.

For manufacturers requiring flexibility and tailored solutions, the Customized Graphite CNC Machine Tool offers a comprehensive platform for machining complex graphite parts. The machine integrates seamlessly with systems like the Five-Axis Vertical Milling Machining Center, which is capable of performing multi-dimensional cuts with high accuracy. This enables the efficient processing of graphite round rods and the outer circles of various graphite components with exceptional precision. Whether producing small batches or large volumes of custom graphite products, this versatile solution supports a wide variety of applications. The ability to work with various forms of graphite, including wear-resistant materials, ensures that the machine can meet the most demanding production needs while maintaining high-quality standards throughout the process. This advanced CNC lathe technology is designed to provide reliable, accurate, and efficient results for businesses focused on precision graphite machining.
