5 Axis CNC Machining Center for Graphite S-500V

Guangdong Shangshan Precision Machinery Co., Ltd.

Main products: Graphite milling machine, Graphite lathe, Vertical/Gantry graphite machine

Graphite machine model:S--500V,S--640V,S--960V,S--1100V,S--1500V,S--2500G

Gantry graphite machine model:S--1000G,S--1200G,S--1350G,S--1615G

Graphite lathe model:S--500NC,S--750NC,S--6550NC,S--8665NC

Factory direct sales, support customization

If necessary, please contact me  WhatsAPP:+8613510109008

X/Y/Z Travel:                    500×400×400mm

Worktable Dimensions:           600×400mm

Worktable Load Capacity:         200Kg

Spindle Face to Worktable Height:  130—530mm

Positioning Accuracy:            ±0.005/300mm

Repeatability Positioning Accuracy:                  ±0.003/300mm

Tool Magazine Capacity:          24

Spindle Speed:                 12000－40000Rpm

Moving Speed:                 15m-48m/min

Cutting Speed:                 10m-20m/min

Tool Change Time:              2 seconds

Machine Tool Dimensions:       2100×2180×2450mm

Machine Tool Weight:           3600Kg

Control Method:               Fully closed-loop control

Can it be customized?:          Supports customization
