BL165G-SFP Gigabit 1 Optical 4 Electrical Switch for Data Transmission in Industrial IoT

Name: BL165G-SFP Gigabit 1 Optical 4 Electrical Switch for Data Transmission in Industrial IoT
Brand: BLIIOT
Availability: InStock

FOB Price

US$ 41.27 - 44.44 / Piece

1 Piece(Min. Order)

Port Shenzhen
Payment TermsT/T PayPal Cash
Delivery Detail15 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	BLIIOT		Place of Origin	China
Model Number	BL165G-SFP

Product Description

4 gigabit electrical port +1 gigabit FX optical port industrial Ethernet switch BL165G supports 4 10Base-T/100Base-T/1000Base-TX electrical port and 1 1000Base-X optical port. Products comply with FCC, CE, ROHS standards. BL165G switch has a working temperature of -40℃ ~ 75℃, with super robustness to adapt to a variety of harsh environments, can also be very convenient to be placed in a compact space control box. The rail installation features, wide temperature operation, IP40 enclosure and LED indicator light make the BL165G a plug-and-play industrial device, providing a reliable and convenient solution for users to network their Ethernet devices.

v The use of high-quality photoelectric integration module to provide good optical and electrical characteristics;

v Ensure reliable data transmission and long working life;

v Support full-duplex or half-duplex mode, with automatic negotiation ability;

v Network port supports automatic cross identification;

v With store and forward mechanism, support a variety of protocols;

v Meet industrial operation standards, the average trouble-free work in more than 300,000 hours;

v Working power supply: DC 12-52V provides reverse connection protection;

v Use SC/FC/ST/SFP optical fiber interface;

v Lightning surge impact protection (power supply) : 5000A(8/20μs).

Product Parameters

BL165G specification introduction
Power	Power Input	DC12-52V（Dual Power Redundant Backup）
	Access terminal	Phoenix terminal
	Dual power redundancy	Support
	Built-in overcurrent 4.0A protection	Support
	Reverse connection protection	Support
LED Indicators	Power indicator	PWR
	Interface indicator	Electric port,Fiber port（Link/ACT）
RJ45 Ports	RJ45 specification	4xRJ45,10/100/1000BaseT（X）automatic detection,MDI/MDI-X adaptive
	Standards	IEEE802.310BASE-TIEEE802.3i；10Base-T；IEEE802.3u；100Base-TX/FX；IEEE802.3ab1000Base-T； IEEE802.3z1000Base-X；IEEE802.3x
Fiber Ports	Fiber ports specification	1x1000BaseFX ports（SC/FC/ST/SFP optional）
Switch properties	Transmission mode	Store-and-forward
	Packet Buffer Memory	1.2Mbit
	Switching delay	<10μs
	MAC Address Table	2K
	Bandwidth	14G
	Power dissipation	<3W
Certification	MTBF	300,000 hours
	EMI	FCC Part 15 Subpart B Class A，EN 55022 Class A
	EMC	IEC(EN)61000-4-2(ESD)：±6kV(contact),±8kV(air)
		IEC(EN)61000-4-3(RS)：10V/m(80～1000MHz)
		IEC(EN)61000-4-4(EFT)：Power Port : ±2kV CM//±1kV DM
		IEC(EN)61000-4-5(Surge)：Power Port : ±2kV CM//±1kV DM
		IEC(EN)61000-4-6：3V(10kHz～150kHz)，10V(150kHz～80MHz)
		IEC(EN)61000-4-16：30V cont. 300V,1s
		IEC(EN )61000-4-8
		Shock ：IEC 60068-2-27
		Freefall ：IEC 60068-2-32
		Vibration ：IEC 60068-2-6
Working Environment	Working temperature	-40～75 ℃
	Storage temperature	-40～80 ℃
	Relative Humidity	5%～95%( no condensation）
Mechanical properties	Shell	Metal shell
	Dimensions	118x 86x 33mm
	Protection type	IP40
	Weight	0.36Kg
	Installation method	DIN rail
	Heat dissipation mode	Natural cooling, no fan
Warranty	Warranty period	1 year
