WTD-02 Taber Stiffness Tester is used to measure the bending resistance of paper and paperboard by the Taber-type tester.
The method is primarily used for papers with a high grammage. In the test, the bending moment required to deflect the free end of a 38 mm wide vertically clamped specimen by 15° when the load is applied at a bending length of 50 mm, is obtained. For boards that tend to be permanently deformed if bent through 15°, the half bending angle 7.5°, can be used.
The bending resistance is expressed in terms of the bending moment and is expressed in millinewton meters mN·m.
Test PrincipleA test piece of defined dimensions is bent through a specified bending angle. The resulting bending moment is read from the instrument scale.
StandardsASTM D5342，ASTM D5650，ASTM D3301， BS ISO 2493.2，ISO 2493.2, JIS P8125.2，TAPPI T489，TAPPI T566, GB/T 2679.3, GB/T 22364
Main Parameters| Test range | 1~500 mN.m (in 7 ranges) |
| Indication error | ±2% |
| Bending length | 50mm±0.1mm |
| Testing speed | （200°±20°）/min |
| bending angle | 15°±0.3° and 7.5°±0.3° |
| Sample size | 38*70 mm |
| Dimension | 220*230*350mm |
| Net weight | 15kg |
| Power | AC 220V 50Hz |
