SAPHIR 700V0 12V-70Ah C/20 SAPHIR BATTERY

SAPHIR 700V0 12V-70Ah C/20 SAPHIR BATTERY thumbnail-1
SAPHIR 700V0 12V-70Ah C/20 SAPHIR BATTERY thumbnail-2
SAPHIR 700V0 12V-70Ah C/20 SAPHIR BATTERY thumbnail-3
SAPHIR 700V0 12V-70Ah C/20 SAPHIR BATTERY thumbnail-4
SAPHIR 700V0 12V-70Ah C/20 SAPHIR BATTERY thumbnail-5
SAPHIR 700V0 12V-70Ah C/20 SAPHIR BATTERY photo-1
SAPHIR 700V0 12V-70Ah C/20 SAPHIR BATTERY photo-2
SAPHIR 700V0 12V-70Ah C/20 SAPHIR BATTERY photo-3
SAPHIR 700V0 12V-70Ah C/20 SAPHIR BATTERY photo-4
SAPHIR 700V0 12V-70Ah C/20 SAPHIR BATTERY photo-5
CNY 1380 - 1520 MOQ: 1 Bag
Key Specifications
Get Latest Price
Brand Name:
SAPHIR
Place of Origin:
China
Model Number:
SAPHIR 700V0 12V-70Ah C/20
Contact Supplier Request Quote Chat Now
Steco Battery Limited.ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Hong Kong
Delivery Detail:
5 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name SAPHIR
Place of Origin China
Model Number SAPHIR 700V0 12V-70Ah C/20
Size 262x165x165mm
Weight 24KG
Voltage 12V
Usage Other, Ship's main propulsion motor equipment
Nominal Capacity 70Ah
Maintenance Type Free
Sealed Type Sealed

SAPHIR 700V0 12V-70Ah C/20 SAPHIR BATTERY


Ref. Voltage (Volts) Capacity Ah in 10h Length Width Height Drawing No. Type of connexion Weight (kg)
Saphir2V100 2 100 97 25 57 1 M6
Saphir2V150 2 150 98 48 57 2 M8
Saphir2V200 2 200 178 34 66 3 M8
Saphir2V300 2 300 134 34 66 4 M8
Saphir2V400 2 400 134 67 66 5 M8
Saphir2V500 2 500 151 65 100 6 M8
Saphir2V600  2 600 151 50 100 7 M8
Saphir2V800 2 800 151 101 100 8 M8
Saphir2V1000  2 1000 151 98 100 9 M8
Saphir2V1200  2 1200 181 76 167 10 M8


LOW CAPACITY BATTERIES


Ref. Voltage (Volts) Capacity Ah in 20h Length Width Height Drawing No. Type of connexion Weight (kg)
SAPHIR 12S 6 1,3 97 25 57 1 A 0,28
SAPHIR 12 V0 12 1,3 98 48 57 2 A 0,56
SAPHIR 20 V0 12 2,4 178 34 66 3 A 0,95
SAPHIR 30S 6 3,2 134 34 66 4 A 0,62
SAPHIR 30 V0 12 3,2 134 67 66 5 A 1,20
SAPHIR 65 V0 12 6,8 151 65 100 6 A 2,45
SAPHIR 100S 6 10,8 151 50 100 7 A 1,90
SAPHIR 100 V0 12 10,8 151 101 100 8 A 4,00
SAPHIR 120 V0 12 12,8 151 98 100 9 B 4,00
SAPHIR 150 V0 12 17,2 181 76 167 10 C 5,90



MIDDLE AND HIGH CAPACITY BATTERIES


Ref. Voltage (Volts) Capacity Ah in 20h Length Width Height Drawing No. Type of connexion Weight (kg)
SAPHIR 240 V0 12 26,0 175 125 166 21 J 8,80
SAPHIR 380 V0  12 38,0 197 165 169 22 G 13,50
SAPHIR 500 V0  12 50,0 280 165 207 23 G 18,20
SAPHIR 600 V0 12 58,0 280 165 207 23 G 18,70
SAPHIR 800 V0 12 86,0 360 164 227 24 G 31,00
SAPHIR 1100 6 118,0 280 165 207 25 H 20,00
SAPHIR 1600 4 170,0 280 165 207 23 H 20,50
SAPHIR 3600 2 350,0 280 165 207 25 H 20,50
SAPHIR 4500 2 460,0 205 200 267 26 H 29,50


CONSTANT CURRENT DISCHARGE


Ref. 10 min 15 min 20 min 30 min 1 hr 2 hr 3 hr 4 hr 5 hr 8 hr 10 hr 20 hr 36 hr 72 hr 100 hr
SAPHIR 12 3.7 2.75 2.2 1.55 0.86 0.49 0.36 0.28 0.235 0.155 0.13 0.066 0.087 0.019 0.014
SAPHIR 20 6.4 4.9 3.9 2.8 1.55 0.88 0.62 0.49 0.41 0.28 0.23 0.122 0.069 0.036 0.026
SAPHIR 26 7.5 5.7 4.6 3.3 1.82 1.03 0.73 0.57 0.48 0.33 0.27 0.143 0.081 0.042 0.031
SAPHIR 30 8.3 6.4 5.1 3.65 2.02 1.15 0.81 0.63 0.53 0.36 0.3 0.16 0.091 0.047 0.034
SAPHIR 65 16.3 12.6 10.3 7.6 4.2 2.4 1.75 1.38 1.18 0.79 0.65 0.35 0.2 0.105 0.077
SAPHIR 100 22 18.2 15.8 12 7 4 2.8 2.17 1.8 1.2 1.05 0.55 0.32 0.17 0.125
SAPHIR 120 30 24 19.5 14 7.8 4.5 3.3 2.55 2.2 1.45 1.2 0.64 0.38 0.198 0.145
SAPHIR 150 39 30.5 25.5 19.2 1.8 6.4 4.5 3.5 3 2 1.65 0.88 0.5 0.26 0.19
SAPHIR 240 53 42 34.5 25 15.5 9.1 6.9 5.25 4.3 2.9 2.41 1.31 0.75 0.4 0.29
SAPHIR 380 73.5 59 48 37 22.5 14 10.4 8 6.5 4.3 3.61 1.92 1.1 0.59 0.44
SAPHIR 500 102 80 66 49.5 31.5 18.5 13.7 10.5 8.5 5.7 4.72 2.52 1.5 0.78 0.58
SAPHIR 600 118.5 95 78 59 37 22 16 12 9.8 6.5 5.52 2.92 1.7 0.89 0.66
SAPHIR 800 174.5 140 115.5 89 54 33 23.6 18 14.6 9.5 8.05 4.31 2.5 1.3 0.96
SAPHIR 1100 212 173 144 110 67 40 30 24 20 13.3 11.1 5.92 3.4 1.73 1.3
SAPHIR 1600 306 245 205 158 98 59.5 44 35 29 19 16.1 8.52 4.9 2.6 1.9
SAPHIR 3600 550 460 400 305 190 117 87 70 58 40 32.6 17.6 10 5.2 3.85
SAPHIR 4500 780 635 550 428 267 158 120 95 78 53 44.2 23.3 13 6.6 4.8


At End Voltage 1.75V

Product Tags: SAPHIR , SAPHIR 700 V0 , 12V70Ah , STECO , STECO SAPHIR
