Home > Industrial Equipment & Components > Industrial Brake > DADH Series Yaw Brake

DADH Series Yaw Brake

Name: DADH Series Yaw Brake
Brand: Hongqiao
SKU: 172650433
Availability: InStock

Jiaozuo Hongqiao Brake Co.,Ltd

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Brand Name:

Hongqiao

Place of Origin:

China

Model Number:

DADH

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai port/Qingdao port

Delivery Detail:

20 days

Product Details
Company Profile
Contact Us

Brand Name Hongqiao

Place of Origin China

Model Number DADH

Applications

Mainly used for yaw braking of wind turbines, and also widely used in lifting transportation, port loading and unloading, engineering vehicles, metallurgy, cables, sling equipment and other industries deceleration brake or parking brake for various mechanical drives.

Main features:

1. Fixed installation design.

2. Normal open design, hydraulic station drive brake, fast action, safe and reliable.

3. High-performance friction material, good temperature resistance, stable friction coefficient.

4. Small brake clearance, short reaction time, faster braking.

Equipped with leakage oil port, safe and reliable.

Use conditions:

(1) Ambient temperature: normal temperature type -20℃~+50C; low temperature type -40%℃~+509C

(2) Low temperature brake hydraulic oil should be able to operate normally under low temperature ambient temperature.

(3) There should be no flammable, explosive gases and media in the working environment.

(4) Relative humidity of air ≤95%.

Technical data

Model	Piston diameter (mm)	Working pressure (Mpa)	Max pressure (Mpa)	1 mm Stoke flow (cm^3)	Nominal friction coefficient (u)	Brake pad max wear L(mm)	Brake torque (KN, 16Mpa）	Bolt	Weight (kgs)
DADH75	75	16	20	18	0.4	6	107	M20	60
DADH80	80	16	20	20	0.4	6	122	M24	63
DADH90	90	16	20	26	0.4	6	154	M27	65
DADH120	120	16	18.5	68	0.4	6	412	M32	250
