SIT1051AT/3 SOP-8 CAN Transceiver SIT (Xinlite) Brand New Original Equipment

describe

SIT1051A is an interface chip used between CAN protocol controllers and physical buses, which can be applied in fields such as trucks, buses, cars, industrial control, etc. It supports 5Mbps flexible data rate CAN FD and has the ability to transmit differential signals between buses and CAN protocol controllers.

SIT1051A is an upgraded version of the SIT1051 chip, which improves the symmetry of the bus signal and has lower electromagnetic radiation performance. Additionally, SIT1051A is fully compatible with SIT1051.

characteristic

Fully compatible with the ISO 11898 standard;

Built in over temperature protection function;

Bus port ± 70V withstand voltage;

Driver (TXD) explicit timeout function;

Silent reception mode;

SIT1051AT/E has a low-power shutdown mode;

SIT1051AT/3 I/O voltage range supports 3.3V and 5V MCU;

VCC and VIO power pins have undervoltage protection function;

High speed CAN, supporting 5Mbps CAN FD flexible data rate;

The typical loop delay from TXD to RXD is less than 100ns;

High resistance to electromagnetic interference;

Non powered nodes do not interfere with the bus;

Supports DFN3 * 3-8, small form factor, no pin packaging
