Physical Testing Digital Multi-range Torque Wrench Calibrator Tester

Name: Physical Testing Digital Multi-range Torque Wrench Calibrator Tester
Brand: NANBEI
SKU: 172511303
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

NANBEI

Place of Origin:

China

Model Number:

ANJ-30 /ANJ-50 /ANJ-100 /ANJ-200 /ANJ-300 /ANJ-500 /ANJ-1000

Nanbei Instrument Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Brand Name NANBEI

Place of Origin China

Model Number ANJ-30 /ANJ-50 /ANJ-100 /ANJ-200 /ANJ-300 /ANJ-500 /ANJ-1000

Digital Multi-range Torque Wrench Calibrator Tester

Usage and Application

ANJ torque wrench tester is a test torque wrench, torque screwdriver special equipment

Mainly used to detect a variety of fixed-type torque wrench, digital torque wrench, preset torque driver,

torque screwdriver, screwdriver and other equipment involved in tightening force and products.

Widely used in electrical manufacturing, machinery manufacturing, automotive light industry, professional research

and testing industry.

Feature

1. High precision, high resolution, sampling speed, full screen display.

2. The use of high-precision torque sensor, with torque direction display.

3. The upper and lower limits of the set, red and green light and the sound of light and light alarm.

4. The three units are converted to each other (N.m, kg.cm, Ib.in).

5. Real-time, peak, automatic peak three modes can be free to switch.

6. Using USB interface and PC communication, synchronization test function can be connected to computer testing,

computer synchronization display test curve and test the test process of detailed records, and do save, print and

other analysis.

7. Peak hold, auto release function, release time free setting.

8. Storage capacity, can save 1000 sets of test data.

9. No operation Automatic shutdown function, the time can be set freely.

Technical data

Model		ANJ-30	ANJ-50	ANJ-100	ANJ-200	ANJ-300	ANJ-500	ANJ-1000
Measurement range / scale value	N.m	30.000/0.001	50.000/0.001	100.00/0.01	200.00/0.01	300.00/0.01	500.00/0.01	1000.0/0.1
	Kgf.cm	306.31/0.01	510.52/0.01	1021.0/0.1	2042.0/0.1	3063.1/0.1	5105.2/0.1	10210/1
	lbf.in	265.86/0.01	443.11/0.01	886.2/0.1	1772.4/0.1	2658.6/0.1	4431.1/0.1	88622/1
Dimension		645mm×420mm×220mm		1050mm×540mm×300mm				1433mm×685mm×360mm
Check length range		150mm~450mm		150mm~870mm				150mm~1200mm
Width stroke		210mm		330mm				450mm
Height stroke		90mm		140mm
Accuracy		±1%
Peak sampling frequency		2000HZ
Power		7.2V 1.2V×6 Ni-MH rechargeable battery pack
Charging time		4~6h
Battery continuous use of time		About 10 hour
Battery		≥300 time
Power Adapter		Input AC220V50HZ output:DC10V300mA
Net weight		30kg		55kg				110kg
