Mirekold Energy Monocrystalline Solar Panel 166 Series 40W 500W China Factory Solar Panel

Mirekold Energy Monocrystalline Solar Panel 166 Series 40W 500W China Factory Solar Panel thumbnail-1
Mirekold Energy Monocrystalline Solar Panel 166 Series 40W 500W China Factory Solar Panel thumbnail-2
Mirekold Energy Monocrystalline Solar Panel 166 Series 40W 500W China Factory Solar Panel thumbnail-3
Mirekold Energy Monocrystalline Solar Panel 166 Series 40W 500W China Factory Solar Panel thumbnail-4
Mirekold Energy Monocrystalline Solar Panel 166 Series 40W 500W China Factory Solar Panel thumbnail-5
Mirekold Energy Monocrystalline Solar Panel 166 Series 40W 500W China Factory Solar Panel photo-1
Mirekold Energy Monocrystalline Solar Panel 166 Series 40W 500W China Factory Solar Panel photo-2
Mirekold Energy Monocrystalline Solar Panel 166 Series 40W 500W China Factory Solar Panel photo-3
Mirekold Energy Monocrystalline Solar Panel 166 Series 40W 500W China Factory Solar Panel photo-4
Mirekold Energy Monocrystalline Solar Panel 166 Series 40W 500W China Factory Solar Panel photo-5
US$ 0.09 - 0.12 MOQ: 200 Pieces
Key Specifications
Get Latest Price
Brand Name:
Mirekold
Place of Origin:
China
Model Number:
MK450W24V144M166
Contact Supplier Request Quote Chat Now
Youwei Electronic Commerce (Hangzhou) Co., Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Mirekold
Place of Origin China
Model Number MK450W24V144M166
Material Monocrystalline Silicon
Size 1950*990*35*25
Max. Power 450
Number of Cells 32
Monocrystalline module model Peak power Peak operating voltage Peak operating current open circuit voltage short circuit current ) 166Monocrystalline cell chip Component size Junction box specifications and models Packing box
    W*L*H(mm)
Company abbreviation, power watts, battery voltage volts, number   of cells in series, monocrystalline cell specifications Pmax（W     ) Vmp     ( V ) Imp（A） Voc（V) Isc（A） Single   crystal 166 *166Battery chip dicing specifications and serial chip quantity   description long   *Width *Border height *Installation side width Photovoltaic   junction box model accessories description regular   packaging says
MK40W12V32M166 40 18.75 2.13 21.95 1.05 Divide 166 *33.2MM32 string 600*370*25*20 SY026     1*10Diode double hole without wire 5Pieces in a carton without inner box

MK50W12V32M166 50 18.72 2.67 21.92 2.8 Divide   166 *41.5MM32 string 740*370*25*20 SY026     1*10Diode double hole without wire 5Pieces   in a carton without inner box
MK65W12V32M166 65 18.49 3.51 21.72 3.69 Divide   166 *55.3MM32 string 500*710*25*20 SY027     2 15 ADiode double hole without wire 5Pieces   in a carton without inner box
MK75W12V36M166 75 21.06 3.55 24.66 3.73 Divide   166 *55.3MM36 string 540*750*25*20              SY027     2 15 ADiode double hole without wire 5Pieces   in a carton without inner box
MK75W12V36M166 75 21.06 3.55 24.66 3.73 Divide   166 *55.3MM36 string 540*730*25*20 SY027     2 15 ADiode double hole without wire 2Pieces   in a carton without inner box
MK80W12V32M166 80 18.72 4.27 21.92 4.48 Divide   166 *66.4MM32 string 600*710*25*20 SY027     2 15 ADiode double hole without wire 2Pieces   in a carton without inner box
MK90W12V32M166 90 18.72 4.27 21.92 4.48 Divide   166 *66.4MM36 string 870*540*25*20                  SY027     2 15 ADiode double hole without wire 2Pieces   in a carton without inner box
MK110W12V36M166 110 20.88 5.26 24.48 5.53 Divide   166 *83MM36 string 1070*540*30*25 SY027     2 15 ADiode double hole without wire 2Pieces   in a carton without inner box
MK100W12V33M166 100 19.07 5.24 22.4 5.5 Divide   166 *83MM33 string 980*540*30*25 SY027     2 15 ADiode double hole without wire 2Pieces   in a carton without inner box
MK100W12V32M166 100 18.72 5.34 21.92 5.6 Divide   166 *83MM32 string 720*710*30*25 SY027     2 15 ADiode double hole without wire 2Pieces   in a carton without inner box
MK100W12V36M166 100 19.4 5.15 23.4 5.41 Divide   166 *83MM36 string 810*710*30*25 SY027     2 15 ADiode double hole without wire 2Pieces   in a carton without inner box
MK110W12V36M166 110 20.88 5.26 24.48 5.53 Divide   166 *83MM36 string 810*710*30*25 SY027     2 15 ADiode double hole without wire 2Pieces   in a carton without inner box
MK130W12V64M166 130 18.52 7.01 21.72 7.37 Divide   166 *55.3MM32+32 string 960*710*30*25 SY027     2 15 A Diode strip 60 CM2.5 flat photovoltaic line +mc4 Male and   female heads 2Pieces   in a carton without inner box
MK150W12V72M166 150 19.8 7.55 23.7 8.22 Divide   166 *55.3MM36+36 string 1080*710*30*25 SY027     2 15 A Diode strip 60 CM2.5 flat photovoltaic line +mc4 Male and   female heads 2Pieces   in a carton without inner box
MK180W12V60M166 180 17.4 10.34 20.4 10.86 Divide   166 *83MM30+30 string 1320*710*30*25 PVCQ107     3 20 A Diode 90 CM4 flat photovoltaic line +MC4 Male and female   connector 2Pieces   in a carton without inner box
MK200W12V64M166 200 18.72 10.68 21.92 11.21 Divide   166 *83MM32+32 string 1400*710*30*25 PVCQ107     3 20 A Diode 90 CM4 flat photovoltaic line +MC4 Male and female   connector 2Pieces   in a carton without inner box
MK220W12V72M166 220 20.88 10.53 24.48 11.06 Divide   166 *83MM36+36 string 1560*710*30*25 PVCQ107     3 20 A Diode 90 CM4 flat photovoltaic line +MC4 Male and female   connector 2Pieces   in a carton without inner box
MK225W12V72M166 225 21.06 10.68 24.66 11.21 Divide   166 *83MM36+36 string 1560*710*30*25 PVCQ107     3 20 A Diode 90 CM4 flat photovoltaic line +MC4 Male and female   connector 2Pieces   in a carton without inner box
MK250W24V120M166 250 35.1 7.12 41.1 7.47 Divide   166 *55.3MM60+60 string 1200*1038*35*25 PVCQ107     3 20 A Diode 90 CM4 flat photovoltaic line +MC4 Male and female   connector 30A   pallet plus a box
MK300W24V144M166 300 42.12 7.12 49.24 7.47 Divide   166 *55.3MM72+72 string 1430*1038*35*25 PVCQ107     3 20 A Diode 90 CM4 flat photovoltaic line +MC4 Male and female   connector 30A   pallet plus a box
MK320W24V108M166 320 30.78 10.39 36.18 10.91 Divide   166 *83MM54 string+54 string 1570*1038*35*25 PVCQ107     3 20 A Diode 90 CM4 flat photovoltaic line +MC4 Male and female   connector 30A   pallet plus a box
MK335W24V108M166 335 31.45 10.65 36.88 11.18 Divide   166 *83MM54 string+54 string 1570*1038*35*25 PVCQ107     3 20 A Diode 90 CM4 flat photovoltaic line +MC4 Male and female   connector 30A   pallet plus a box
MK340W24V108M166 340 31.86 10.67 37.26 11.2 Divide   166 *83MM54 string+54 string 1570*1038*35*25 PVCQ107     3 20 A Diode 90 CM4 flat photovoltaic line +MC4 Male and female   connector 30A   pallet plus a box
MK370W24V120M166 370 34.92 10.59 40.92 11.11 Divide   166 *83MM60 string+60 string 1755*1038*35*25 Triple   junction box model XC022X with cord MC4 Connector 30A   pallet plus a box
MK380W24V120M166 380 35.4 10.73 41.5 11.27 Divide   166 *83MM60 string+60 string 1755*1038*35*25 Triple   junction box model XC022X with cord MC4 Connector 30A   pallet plus a box
MK430W24V144M166 430 41.61 10.33 48.81 10.85 Divide   166 *83MM72 string+72 string 2094*1038*35*35 Triple   junction box model XC022X with cord MC4 Connector 30A   pallet plus a box
MK450W24V144M166 450 42.12 10.68 49.32 11.21 Divide   166 *83MM72 string+72 string 2094*1038*35*35 Triple   junction box model XC022X with cord MC4 Connector 30A   pallet plus a box
MK455W24V144M166 455 42.48 10.71 49.68 11.24 Divide   166 *83MM72 string+72 string 2094*1038*35*35 Triple   junction box model XC022X with cord MC4 Connector 30A   pallet plus a box
MK480W24V156M166 480 44.2 10.87 52.9 11.57 Divide   166 *83MM78 string+78 string 2256*1038*35*35 Triple   junction box model XC022X with cord MC4 Connector 30A   pallet plus a box
MK490W24V156M166 490 44.6 11 53.3 11.67 Divide   166 *83MM78 string+78 string 2256*1038*35*35 Triple   junction box model XC022X with cord MC4 Connector 30A   pallet plus a box
MK500W24V156M166 500 45 11.12 53.5 11.77 Divide   166 *83MM78 string+78 string 2256*1038*35*35 Triple   junction box model XC022X with cord MC4 Connector 30A   pallet plus a box


Product Tags: solar panel , Monocrystalline solar panel , Monocrystalline solar element , solar element , longi , Jinko
