IEC60529 Dust Chamber for IP5X and IP6X Testing

Dust Test Chamber

1. Introduction

The sand and dust test chamber helps to evaluate the ability of the equipment to withstand the effects of dust, it is apply to test various auto parts includes lamps, instrument, electric dust cover, steering system, door lock and etc., as well as inspection of product sealing performance. Meet the test requirement of IP5X and IP6X enclosure protection levels as specified in IEC60529.

The dust chamber is controlled by 7 inch touch screen and PLC system, the interior of the cabinet is equipped with lighting and power supply, which can be used for live dust-proof test of the sample to simulate a more realistic use environment. There is a mesh sample support plate inside the box for Dust recycling, it is made of stainless steel and has a load capacity of 50KG.

IP5X dustproof test chamber: the protection is satisfactory if the power has no accumulated in a quality which may interface the correct operation and cause harmful to equipment.

IP6X dustproof test chamber: the protection is satisfactory if no deposit of dust is observable inside the enclosure at the end of the test

2. Specification
