Full Automatic UHT Plate sterilizer
- 1000 per Month
- T/T Credit Card
- Liquid Beverage Production Line Spray Cooling Sterilization Machine
- Spider Hand Bottle Dryer Automatic Tunnel Dryer Machine for Glass Bottles
- Automatic Sleeve Shrink Wrapping Bottle Machine Wrap System
- CIP Cleaning System for Juice drinks beverage Processing
- automatic Air cooled mill sugar salt crusher Stainless steel crusher
- Stainless Steel Food Grade Automatic 304 Ss Food Grade Vertical Z Type Bucket Elevator Conveyor
Product Description
1.Technology Parameter of UHT Sterilizer :
Parameters
Temperature profile: 5°C→65°C →95°C / 30S→140°C / 4S→25°C
Ice water 1:1 (≤2°C Spare) Cooling water 1:1(30°C Spare)
Model | UHT-1T | UHT-2T | UHT-3T | UHT-4T | UHT-5T | UHT-6T | UHT-8T | UHT-10T |
Production capacity (T/H) | 1 | 2 | 3 | 4 | 5 | 6 | 8 | 10 |
Heat exchanging area (m2) | 20 | 28 | 35 | 45 | 52 | 60 | 75 | 88 |
Material inlet temperature (°C) | ≤15 | ≤15 | ≤15 | ≤15 | ≤15 | ≤15 | ≤15 | ≤15 |
Material outlet temperature (°C) | ≤25 | ≤25 | ≤25 | ≤25 | ≤25 | ≤25 | ≤25 | ≤25 |
Designed temperature (°C) | 150 | 150 | 150 | 150 | 150 | 150 | 150 | 150 |
Heat preservation time | 5s | 5s | 5s | 5s | 5s | 5s | 5s | 5s |
Inlet temperature of ice water (°C) | ≤2 | ≤2 | ≤2 | ≤2 | ≤2 | ≤2 | ≤2 | ≤2 |
Multiple of ice water | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 |
Plate pasteurizer machine is an equipment specializing in sterilizer with milk,yogurt, beverage and similar liquid materials. The equipment is the ideal equipment make the materials sterilize ,cool and delay the, and can design according to users different craft requirement for material heating, sterilizing, keeping warm, cooling, to satisfy all kinds of craft require. Have the function of safety protection measures and alarm system high temperature, low temperature water-regurgitating. Meanwhile, can deploy high accuracy automatic control system according to users requirement.
The system adopts HTST processing method, makes liquid dairy products, plant protein milk, juice beverage, tea and other liquid ect. strictly sterilized, then into aseptic package, with the sterilization temperature:85C-120c,warm keeping time:4-25S,so finally keep the original nutrition , color and flavor of the beverage and dairy. Quality guarantee period:6-12 months, The machine has the advantage of high heat recycle,compact and fine structure, and temperature control. Outputting material temperature, and cool package
Company Profile
Shanghai Genyond Technology Co., Ltd. is a manufacturer of extracting unit and fruit & vegetable processing line with well-equipped testing facilities and strong technical force.
With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in food and beverage and other industries.
Our products are widely recognized and trusted by users and can meet continuously changing economic and social needs.
We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success!
