Vertical parting boxless molding machine
- 10 Bag / Bags per Month
- T/T L/C
Product Description
Vertical Parting Boxless Molding Machine is mainly used in automatic green sand casting workshop, which needs to be used in combination with green sand recycling processing equipment, because this equipment requires high quality of green sand, which needs to remove the iron bean splinter etc. in the old sand, and also needs to regenerate the old sand, 120-300 moulds/h, which is a special molding equipment for pedestrian cover, and the hardness of the mould sand is HB80-90 on average.
Model |
Mold size:mm |
|
|
Compaction pressure:Mpa |
|
]productivity:Box/hour
|
hydraulic pressure:Mpa |
power |
ZTD416 |
600×480×(120-330) |
Injection compaction + compaction
|
PLC/touch screen |
1.0-1.2 |
85-90 |
Sand mold thickness: 160mm, type 300 / h (core thickness: 120-180 / h) |
10 |
53 |
ZTD417 |
700×560×(120-330) |
Injection compaction + compaction
|
PLC/touch screen |
1.0-1.2 |
85-90 |
Sand mold thickness: 160mm, type 240 / h (core thickness: 120-180 / h) |
10 |
70 |
ZTD418 |
800×600×(120-330) |
Injection compaction + compaction
|
PLC/touch screen |
1.0-1.2 |
85-90 |
Sand mold thickness: 160mm, type 240 / h (core thickness: 120-180 / h) |
10 |
70 |
ZTD4110 |
1000×1100×(120-330) |
Injection compaction + compaction
|
PLC/touch screen |
1.0-1.2 |
85-90 | Sand mold thickness: 160mm, type 240 / h (core thickness: 120-180 / h) |
10 |
70 |
