Help CenterHoneywell V4055A,B,D,E On-Off Fluid Power Gas Valve Actuator Spot Goods
Related Products
-
Honeywell C7007A, C7008A, C7009A Flame Rod Holder & Flame Rod AssembliesNegotiableMOQ: 1 Unit -
Honeywell C7061A,F Dynamic Self-Check Ultraviolet Flame DetectorNegotiableMOQ: 1 Unit
-
Honeywell L404A-D, F; L604A,L Pressuretrol Controllers AgentNegotiableMOQ: 1 Unit
-
Honeywell RA890F Flame Safeguard Primary Control AgentNegotiableMOQ: 1 Unit
-
Honeywell Series 71, 72, and 76 Modutrol IV™ Motors AgentNegotiableMOQ: 1 Unit
• The standard model has an opening time of 26 seconds at 60 Hz or 32 seconds at 50 Hz. A fast-opening model is available with timings of 13 seconds at 60 Hz or 16 seconds at 50 Hz.
• Maximum closing time is one second, which meets code, standard and insurer requirements.
• Models available with damper shaft, with or without spring return; shaft extends out both sides and rides in Teflon-like Delrin bushings; used with standard 7616BR Damper Crank Arm.
• Red OPEN indicator attached to actuator stem shows when valve is even slightly open; yellow SHUT indicator on valve stem shows only when gas valve is fully closed.
• Models available with adjustable max flow limit switch.
• Ambient temperature rating is -40°F to +150°F (-40°C to +66°C) for 60 Hz models and -10°F to +158°F (-23°C to +70°C) for 50 Hz and 50/60 Hz models.
• Valve and actuator combinations can be mounted in any position, with the exception of the 220 to 240 Vac, 50/60 Hz models, which are mounted vertically.
• Models available with factory-installed single pole double throw (spdt) field-adjustable Auxiliary Switch. Field-addable Auxiliary Switch kits are also available.
• Standard enclosure meets NEMA 1 (IP30) requirements; models available with NEMA 4 (IP54) weatherproof enclosure.
• V4055D and high pressure V4055E with Proof-of-Closure Switch and V5055/V5097C or E with valve seal overtravel interlock (double seal) to meet specific code, standard and insurer requirements. a VE5000 is a European manufactured and approved valve for European use only.
APPLICATION
The V4055 Gas Valve Actuator, in combination with a VE5000a, V5055 or V5097 Gas Valve, controls the gas supply to commercial and industrial burners. When replacing a V4034 with a V4055, the V5034 gas valve must also be replaced with a V5055 or V5097 gas valve.
FEATURES • The V4055 Actuator, when used with the VE5000a, V5097 or V5055 Valve, is rated for final safety shutoff service. • The V4055 Actuator can be used with the characterized guide model of the V5055 or V5097 Gas Valve to enhance lightoff smoothness.
