3BHB004661R0001 Optoelectronic Interface

Shenzhen Xunji Profibus DP bus to fiber optic communication module, Ci-PF110 supports one fiber optic interface and one DP electrical interface, Ci-PF120 supports two cascaded up and down fiber optic interfaces, and one DP electrical interface.

Bus data interface

*DB9F interface form

*The bus data interface is fully compatible with the Profibus-DP bus cable interface, with a communication rate of 6Mbps (optional 12Mbps)

*Isolation voltage: Instantaneous isolation voltage 5000V, continuous isolation voltage 1000V

*Terminal resistance: There is no terminal resistance inside this device. Please decide whether to connect it externally as needed

Fiber optic interface

*Fiber wavelength: multimode 850nm, 1310nm; Single mode 1310nm, 1550nm

*Transmission fiber: multimode 50/125um, 62.5/125um, 100/140um, single mode 8.3/125um, 9/125um, 10/125um

*Transmission distance: multimode 2km, single mode 20km, longer distance optional

*Fiber optic interface type: ST, SC, FC optional, standard ST optical interface

Power supply and protection

*Power supply: Dual power redundant input, DC (9-30V), typical DC24V, power consumption less than 1.5W, with DC1000V voltage isolation and reverse protection function, industrial terminal interface

*Relay alarm output: Fiber optic link fault alarm output, contact capacity: DC48V/1 A, industrial terminal interface

mechanical properties

*External dimensions: 136 * 106 * 54mm

*Shell: IP30 protection level, corrugated aluminum reinforced casing

*Installation method: 35mm guide rail installation

*Net weight: 800g
