Help Center3BSE053240R1 Bus Terminator
Related Products
Performance indicators:
Data electrical interface:
*9-pin Sub_ The D-socket connector and pin definition comply with the protocol specifications of Profibus DP
*Supports the Profibus DP bus standard
*Communication speed: 9.6 kBit/s, 19.2 kBit/s, 45.45 kBit/s, 93.75 kBit/s, 187.5 kBit/s, 500 kBit/s, 1.5 MBit/s, 6 MBit/s, and 12 MBit/s
*Rate setting: automatic recognition or dial switch setting
*Signal delay (electrical port): ≤ 11Bit
*Equipped with 4000V lightning protection, 1.5A overcurrent protection, and 600W surge protection functions;
*Terminal resistance: This device does not come with a terminal resistance, please connect it externally as needed
Fiber optic interface:
*Fiber wavelength: multimode 850nm, 1310 nm; Single mode 1310 nm, 1550 nm.
*Transmission fiber: multimode 50/125 um, 62.5/125 um, 100/140 um; Single mode 8.3/125um, 9/125um, 10/125um.
*Transmission distance: Multi mode 2Km, single mode 20Km, optional for further distances.
*Fiber optic interface types: SC, FC, ST optional, standard SC optical interface.
*Optical path error rate:
*Signal delay (optical port): ≤ 2.3us/node.
Power supply and protection:
*Power supply: Dual power redundant input, DC (9-36) V, typical DC24V, power consumption less than 4W, with DC1500V voltage isolation and reverse protection function, industrial terminal interface
*Relay alarm output: Fiber optic link fault and power supply fault alarm output, contact capacity: DC48V/1 A, industrial terminal interface
Mechanical characteristics:
*External dimensions: 132mm * 105mm * 52mm
*Shell: IP30 protection level, corrugated aluminum reinforced casing
*Installation method: 35mm guide rail installation
*Net weight: 800g
Work environment:
*Working temperature: -10-70 ℃ (-40~+85 ℃ wide temperature optional)
*Relative humidity: 5%~95% (without condensation)
*Storage temperature: -40~80 ℃
Contact information: 15359293870
WhatsApp:+86 15359293870
Contact person: KELLY
Email: geabbdcs@gmail.com 386353502@qq.com
Official website:
http://www.geabb.com
Signal type: transistor NPN
Rated level: NPN: 0V (Max. 1.5V)
Single channel rated current: NPN: Max.0.5A (maximum total load current of 2A for 8 consecutive channels)
Port protection (output): overvoltage and overcurrent protection
Electrical isolation: AC 500V
General parameters
Protection level: IP50
Working temperature: 0-55 ℃
Storage temperature: -25~85 ℃
