Help Center3BHE024577R0101 Drive
Related Products
·External network communication interface: SIM/UIM (3.0V/1.8V);
·Communication protocol: customized instrument data communication protocol;
·Support configuration software: multiple configuration software platforms such as Yakong, Likong, Jiekong, Zijinqiao, etc;
·Support fixed IP, domain name resolution, and private APN networking methods;
·Support multiple center reporting functions;
·Provide DLL controls, virtual serial port software, open source interfaces, and facilitate connection with various networking software and other software
·Parameter settings can be set and changed remotely through a computer or mobile phone;
·Dual watchdog design ensures long-term operation without crashing;
·Equipped with signal strength display, network connection, and data transmission indicator lights;
·Industrial grade quality assurance, stable and reliable performance.
Technical parameters
basic function
Complete remote transmission of monitoring station data and remote communication of command information in the data center
Data upload method
4G, 5G, NB lot, LoRa
data interface
RS485/RS232/TTL
Power supply method
Battery powered
Voltage range
DC+5V~+24V
Working current
DC+12V standby current
antenna
Customizable suction cup antenna and adapter cable
work environment
Temperature: -30~70 ℃; Humidity: ≤ 95% without condensation
Contact information: 15359293870
WhatsApp:+86 15359293870
Contact person: KELLY
Email: geabbdcs@gmail.com 386353502@qq.com
Official website:
http://www.geabb.com
Bus data interface
*9-pin Sub_ D-jack connector, pin definition in accordance with Profibus DP protocol specifications
*Supports Profibus DP bus standard
*Signal delay (electrical port): ≤ 4Bit
*Communication speed: 9.6Kbps, 19.2 Kbps, 45.45Kbps, 93.75Kbps, 187.5Kbps, 500Kbps, 1.5Mbps, 3Mbps, 6Mbps, 12Mbps
*Equipped with 4000V lightning protection, 1.5A overcurrent protection, and 600W surge protection functions
*Terminal resistance: This device does not come with a terminal resistance, please connect it externally as needed
Power supply and protection
*Power supply: Dual power redundant input, DC (12-36V), typical DC24V, power consumption less than 4W, with reverse protection function, industrial terminal interface
*Relay alarm output: Bus data interface fault alarm output, contact capacity: DC48V/1 A, industrial terminal interface
mechanical properties
*External dimensions: (136x106x54) mm
*Shell: IP30 protection level, corrugated aluminum reinforced casing
*Installation method: 35mm guide rail installation
*Net weight: 800g
work environment
*Working temperature: -10 ℃~70 ℃, optional wide temperature product (-40~85 ℃)
*Storage temperature: -40 ℃~85 ℃
*Relative humidity: ≤ 90% (non condensing)
