Infineon's 7th generation TRENCHSTOP ™ IGBT is designed specifically for variable frequency industrial drives.
Based on the new micro groove gate technology, higher device controllability can be achieved, which greatly reduces the losses of switching devices in applications, especially in industrial drive applications that typically operate at medium switching frequencies.
Wider product portfolio to meet different application scenarios
The specific product series based on IGBT7 and Emcon7 diode technology are as follows:
The Easy 1B and Easy 2B series can provide PIM configurations with current levels ranging from 10 A to 100 A, as well as six unit configurations;
The Easy 3B series can expand the rich range of Easy products in industrial drive applications to larger current levels: PIM configurations are 50 A, 75 A, and 100 A, and six unit configurations are 100 A, 150 A, and 200 A;
Econo 2 and 3 series, covering a current range of 25 A-200 A;
62mm series, covering current levels of 450A, 600A, and 800A;
EconoDUAL ™ 3 series, covering a current range of 300 A-900 A.
Better product performance, creating more competitive system costs
In short, compared to the previous generation of IGBT4 chips, it has higher power density, higher switching frequency, and can reduce system heat dissipation design, making the overall cost of the system more advantageous.
The service life of the product is the same or longer while keeping the operating conditions unchanged.
Temperature: -30~70 ℃; Humidity: ≤ 95% without condensation
Contact information: 15359293870
WhatsApp:+86 15359293870
Contact person: KELLY
Email: geabbdcs@gmail.com 386353502@qq.com
Official website:
Bus data interface
*9-pin Sub_ D-jack connector, pin definition in accordance with Profibus DP protocol specifications
*Supports Profibus DP bus standard
*Signal delay (electrical port): ≤ 4Bit
*Communication speed: 9.6Kbps, 19.2 Kbps, 45.45Kbps, 93.75Kbps, 187.5Kbps, 500Kbps, 1.5Mbps, 3Mbps, 6Mbps, 12Mbps
*Equipped with 4000V lightning protection, 1.5A overcurrent protection, and 600W surge protection functions
*Terminal resistance: This device does not come with a terminal resistance, please connect it externally as needed
Power supply and protection
*Power supply: Dual power redundant input, DC (12-36V), typical DC24V, power consumption less than 4W, with reverse protection function, industrial terminal interface
*Relay alarm output: Bus data interface fault alarm output, contact capacity: DC48V/1 A, industrial terminal interface
mechanical properties
*External dimensions: (136x106x54) mm
*Shell: IP30 protection level, corrugated aluminum reinforced casing
*Installation method: 35mm guide rail installation
*Net weight: 800g
work environment
*Working temperature: -10 ℃~70 ℃, optional wide temperature product (-40~85 ℃)
*Storage temperature: -40 ℃~85 ℃
*Relative humidity: ≤ 90% (non condensing)
