Help CenterSolar Power Inverter 6000W
Related Products
Products Specification
1. High efficiency: Jingsun 6000W solar power inverter is highly efficient in converting the direct current (DC) generated by solar panels into alternating current (AC) that can be used to power household and industrial appliances. This increases the overall efficiency of the solar energy system and reduces the amount of energy lost during conversion.
2. Advanced safety features: Solar power inverters are designed with advanced safety features that protect the system from overloading, overvoltage, and short circuits. The 6000W solar power inverter comes equipped with features such as ground fault protection, surge protection, and overcurrent protection to ensure safe and reliable operation.
3. System monitoring: Jingsun 6000W solar power inverters come with system monitoring features that allow users to monitor the performance of their solar energy system remotely. This includes monitoring the amount of energy produced, the amount of energy consumed, and the overall efficiency of the system.
5. Long lifespan: Jingsun Solar power inverters are built to last for many years. With proper maintenance and care, a high-quality solar power inverter can have a lifespan of up to 25 years or more, making it a wise long-term investment for solar power system owners.
Products Specification
Rated Power |
2500W |
3000W |
4000W |
5000W |
6000W |
Surge Power |
5000W |
6000W |
8000W |
10000W |
12000W |
Input Voltage |
12VDC/24VDC/48VDC |
||||
Output Voltage |
110VAC±5%/220VAC±5% |
||||
Switching Mode |
City Power Priority |
||||
Switching Time |
≤10ms |
||||
Charging Current |
20A/10A/5A |
||||
Charging Mode |
Three Stage Charging Mode |
||||
Input Voltage Range |
110VAC±5%/220VAC±5% |
||||
USB Port |
5V 1000MA |
||||
Frequency |
50HZ±3 or 60HZ±3 |
||||
Output Waveform |
Pure Sine Wave |
||||
Soft Start |
YES |
||||
THD/AC Regulation |
THD＜3%(Linear Load) |
||||
Output Efficiency |
94.2% MAX |
||||
No Load Current |
1.2A/0.6A/0.3A |
1.3A/0.7A/0.3A |
2.2A/1.1A/0.6A |
2.6A/1.3A/0.7A |
2.8A/1.5A/0.8A |
DC Voltage Range |
10V-15.5V/21.5V-28V/41.5V-59.5V |
||||
Low Voltage Alarm |
10.5±0.5V/21±0.5V/42±1V |
||||
Low Voltage Shut Down |
10±0.5V/20±0.5V/40±1V |
||||
Low Voltage Recovery |
13±0.5V/24±0.5V/48±1V |
||||
Over Voltage Shut Down |
15.5±0.5V/31±0.5V/61±1V |
||||
Over Voltage Recovery |
14.8±0.5V/29±0.5V/59±1V |
||||
Cooling Way |
Intelligent Cooling Fan |
||||
Protection |
Battery Low Voltage & Over Voltage, Over Load, Over Temperature, Short Circuit |
||||
Working Temperature |
（-10℃+60℃ Civil class，-25℃+60℃ technical grade，-40℃+70℃ army grade） |
||||
Storage Temperature |
（-30℃ - 70℃） |
||||
Humidity |
90% MAX，Non-condensing |
||||
Warranty |
2 Years |
||||
Net Dimension(mm) |
435*165*113 |
450*212*152 |
497*216*151 |
610*216*151 |
610*216*151 |
Package Dimension(mm) |
550*225*175 |
635*308*240 |
635*308*240 |
735*308*240 |
735*308*240 |
N.W./Unit/G.W./Unit |
5.04kg/5.92kg |
8.9kg/10.12kg |
11.14kg/13.4kg |
13.56kg/16.08kg |
14.15kg/16.67kg |
Ctn |
4PCS |
1PCS |
1PCS |
1PCS |
1PCS |
Meas./Ctn(mm) |
570*470*385 |
635*308*240 |
635*308*240 |
735*308*240 |
735*308*240 |
G.W./Ctn |
25.12kg |
10.82kg |
13.48kg |
16.18kg |
16.77kg |
