A4 Thin EL Panels Auto UV Screen Printing Machine
US$ 11000 - 12000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Tamprinter
Place of Origin:
China
Model Number:
TM-3045Z
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Fully Automatic Membrane Switch Screen Printing LineNegotiableMOQ: 1 Set -
High Quality Fully Automatic Membrane Switch Screen Printing Machine LineNegotiableMOQ: 1 Set
-
Fully Automatic Membrane Switch Screen Printing SetNegotiableMOQ: 1 Set
-
Automatic Vertical Sheet Silk Screen Printer With UV DryerNegotiableMOQ: 1 Set
-
Plastic Sheet Clean Room Screen Printing EquipmentNegotiableMOQ: 1 Set
Brand Name
Tamprinter
Place of Origin
China
Model Number
TM-3045Z
Condition
New
Product Description
A4 Thin EL Panels auto UV screen Printing machine
Technical parameters:
Performance & Features
1. This line is composed of vertical screen printer, LED UV dryer.
2. It is a automatic production line which takes off material automatically.
3. After printing finished, robot arm will suck and pull out the printing material, then send it to next working procedure (drying and products collecting).
4. It can not only save human labor, but also improve working efficiency of printing machines.
5. It applies to printing on membrane switch, sheet metal, plastic, plastic film etc.
Please contact us for more information!
Technical parameters:
| TM-5070C vertical screen printer | |
| Printing area | 500X700mm |
| Table size | 600X900mm |
| Max frame | 750X920mm |
| Printing thickness | 0~ 50mm |
| Overlay accuracy | 0.05~0.08mm |
| Platform precision | About +/-0.06mm |
| Printing pressure | 4.0-8.0 kgf/cm2 |
| Air pressure | 0.5~0.6(Mpa) |
| Air consumption | 35L/min |
| Printing speed | 800pcs/h |
| Power | 380V/1.5KW |
| 1330mmX1000mmX1750mm | |
| Weight | 420kg |
| TM-LED600 floor mounted film LED UV dryer | |
| Dimensions (LXWXH) M | 2m*0.8m*1m |
| Irradiation width | 600mm |
| Cooling system | water-cooled system |
| The light measurement range of values | 1000-9500mJ / cm2 |
| Power supply | single-phase 220V 50HZ |
| Weight | 200KG |
Performance & Features
1. This line is composed of vertical screen printer, LED UV dryer.
2. It is a automatic production line which takes off material automatically.
3. After printing finished, robot arm will suck and pull out the printing material, then send it to next working procedure (drying and products collecting).
4. It can not only save human labor, but also improve working efficiency of printing machines.
5. It applies to printing on membrane switch, sheet metal, plastic, plastic film etc.
Please contact us for more information!
