NI PXI-6624 Digital Input Module

Product Introduction

NI PXI-6624 is a digital input module produced by NI (National Instruments). It is a high-performance data acquisition device based on the PXI (PCI eXtensions for Instrumentation) platform, used for measuring and monitoring digital signals. The following are some of the main product features of this module:

Number of channels: The NI PXI-6624 module typically has multiple digital input channels for monitoring multiple digital signals simultaneously.

Input level range: The module supports a wide range of input levels, including common digital level standards such as TTL, CMOS, and LVTTL. This makes it suitable for monitoring and measuring various digital signal sources.

High speed sampling rate: This module has a high-speed digital signal sampling rate to ensure accurate capture and analysis of rapidly changing signals.

Flexible triggering function: The PXI-6624 module has flexible triggering function, which can trigger according to specific conditions of the input signal to achieve precise data collection and triggering control.

Hardware Timer/Counter: Modules typically have integrated hardware timers and counters that can be used to measure and count specific time intervals and pulse events.

Data processing and conversion: The module provides rich data processing and conversion functions, such as digital filtering, state change detection, edge counting, etc., for real-time processing and analysis of input signals.

PXI bus interface: The module adopts a standard PXI bus interface and seamlessly integrates with other PXI modules and devices, facilitating system expansion and interconnection.

Driver software support: This module is equipped with driver software suitable for various programming environments, such as LabVIEW and NI-DAQmx, making it convenient for users to quickly develop, control, and collect data.

Product image display
