NI PXI-2566 Matrix Switch Module

Product Introduction

NI PXI-2566 is a high-speed matrix switch module from National Instruments (NI), belonging to the PXI series of products. It provides flexible matrix switching functions for signal routing and switching in testing and measurement systems. The following is general product information about the NI PXI-2566 module:

High bandwidth and high-speed switching: The PXI-2566 module has high bandwidth and high-speed switching capabilities, suitable for applications that require fast and accurate signal routing. It supports signal bandwidth of up to 6 GHz and provides switching speed in milliseconds.

Multi channel matrix configuration: This module provides multiple matrix configurations to support multi-channel signal switching. It can configure and connect flexible channels according to testing requirements.

Low insertion loss and high isolation: The PXI-2566 module has the characteristics of low insertion loss and high isolation, which can ensure the accuracy and reliability of signal transmission. It adopts high-quality switching components and design to reduce signal loss and mutual interference.

Programmable and remote control: Modules can be controlled through programming and support multiple programming interfaces and software platforms, such as LabVIEW, C/C++, and Python. In addition, it also supports remote control and can integrate and collaborate with other devices.

Flexible module expansion: The PXI-2566 module can be flexibly expanded and combined with other PXI modules and devices to build more complex and multifunctional testing and measurement systems. This can meet the requirements of different application needs.

Product image display
