NI PXI-2570 Relay Module

Product Introduction

NI PXI-2570 is a high-density relay module from National Instruments (NI) designed specifically for testing and automation applications. This module is based on the PXI bus architecture and provides reliable relay switching capabilities. The following are some main features of the NI PXI-2570 relay module:

High density relay: The PXI-2570 module has a high-density relay configuration that can simultaneously control multiple relay channels. It supports multiple independent relay groups, each of which can contain multiple relay channels to meet complex testing requirements.

Fast switching time: This module has fast relay switching time and can complete channel switching at the microsecond level. This helps to improve testing speed and accuracy, especially in applications that require quick switching of multiple signal paths.

High voltage and high current capability: The PXI-2570 module supports relay switches for high voltage and high current, suitable for controlling various electrical signals. It can handle high voltage and current loads and is suitable for applications that require high power.

Low current leakage and contact resistance: The relay module has the characteristics of low current leakage and contact resistance, which can ensure low current leakage in the closed state of the relay and maintain low contact resistance to ensure the reliability and accuracy of signal transmission.

Flexible channel configuration: The module has flexible channel configuration, which can be mapped and configured through software. Users can choose specific channel configurations as needed and flexibly switch channel connections to meet different testing needs.

Software support and integration: The PXI-2570 module can be integrated with NI's software platform and toolset, such as LabVIEW, LabWindows/CVI, and Measurement Studio. This allows for convenient writing of relay control and testing scripts, as well as integration with other instruments and equipment.

PXI platform compatibility: The module is based on the PXI bus architecture and can be compatible with other PXI modules and devices. It can form a complete testing and automation system with other measuring instruments and control equipment.

Product image display
