Product Introduction
NI PXIe-5693 is a high-performance RF signal generator module from National Instruments (NI). It is based on the PXI Express bus architecture and provides a wide range of RF signal generation capabilities. The following are some of the main features of the NI PXIe-5693 module:
High frequency range: The PXIe-5693 module has a wide RF frequency range and is suitable for multiple application fields. It can generate high-frequency RF signals, covering common wireless communication frequency bands.
High frequency resolution and accuracy: The module has the characteristics of high frequency resolution and accuracy, and can generate RF signals with very precise frequency step values. This helps to meet applications that require high frequency accuracy.
Broadband output: The PXIe-5693 module provides broadband RF signal output, which can generate broadband modulated signals and complex RF signal waveforms. It supports modulation techniques such as quadrature amplitude modulation (QAM) and orthogonal frequency division multiplexing (OFDM).
High output power: This module has high output power capability and can provide high RF signal output power. This makes it suitable for applications that require high signal power, such as wireless communication system testing and RF equipment calibration.
Flexible modulation and modulation functions: The PXIe-5693 module supports multiple modulation and modulation functions, including amplitude modulation (AM), frequency modulation (FM), and phase modulation (PM). It can generate various complex RF signal waveforms and provide flexible modulation parameter configurations.
Software support and integration: Modules can be integrated with NI's software platforms and toolsets, such as LabVIEW, LabWindows/CVI, and Measurement Studio. This allows for convenient signal generation, modulation, and measurement, as well as integration with other instruments and equipment.
PXI Express Platform Compatibility: The PXIe-5693 module is based on the PXI Express bus architecture and has characteristics such as high bandwidth, low latency, and scalability. It is compatible with other PXI Express modules and devices, and can form a complete RF testing system with other modules.
Product image display
