NI PXI-2798 Relay Module

Product Introduction

NI PXI-2798 is a relay module produced by NI (National Instruments). This module is used to switch and connect signals in testing and measurement applications. The following are some common product features of this module:

Number of channels: The NI PXI-2798 relay module typically provides multiple independent relay channels, which can simultaneously control multiple signal sources or connect multiple target devices.

Relay types: Modules are typically equipped with multiple relay types, such as single pole single throw (SPST), double pole single throw (DPST), single pole double throw (SPDT), etc., to meet the needs of different applications.

High voltage and high current: The relay module has relays that can withstand high voltage and high current to meet various application requirements.

Low insertion loss: The module has low insertion loss characteristics, ensuring minimal interference and distortion of the signal during switching.

Fast switching speed: The module supports fast switching speed and can achieve signal path switching and connection within milliseconds.

High reliability design: The relay module adopts reliable relay and switch technology, with long lifespan and high stability, suitable for long-term operation and repeated testing.

Flexible triggering and synchronization: The NI PXI-2798 module has flexible triggering and synchronization functions, which can be triggered and synchronized through software or external trigger sources to meet complex application requirements.

Driver software support: The module is equipped with driver software suitable for various programming environments, such as LabVIEW and NI-DAQmx, making it convenient for users to quickly develop and integrate.

PXI bus interface: The module adopts a standard PXI bus interface and seamlessly integrates with other PXI modules and devices, facilitating system expansion and interconnection.

Product image display
