Home > Metallurgy, Mineral & Energy > Wear Resistant Material > Φ22*Φ6*2mm Tungsten Carbide Tile Cutter Replacement Wheels
US$ 1 - 5
MOQ: 2 Pieces
Key Specifications
Get Latest Price
Brand Name:
OSTON
Place of Origin:
China
Model Number:
003
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
25 days
Related Products
-
K10 High Quality Titanium Coating Φ16xΦ6x3mm Titanium Coated Tile Cutting WheelsUS$ 1 - 5MOQ: 2 Pieces -
Tungsten Carbide Shredder Knife Used for Plastic Crushing and E-Waste CrushingUS$ 100 - 400MOQ: 2 Pieces
-
Durable Tungsten Carbide Tyre Shredder Blades for Tyre Shredder Recycling LineUS$ 100 - 400MOQ: 2 Pieces
-
D2/SKD-11/HSS H13 Crushing Blade for Plastic Single Shaft Shredder MachineUS$ 100 - 400MOQ: 2 Pieces
-
43X43X19.5mm Tungsten Carbide/Tool Steel Rotary and Stationary Blades for Micromat 2500 ShredderUS$ 100 - 400MOQ: 2 Pieces
Brand Name
OSTON
Place of Origin
China
Model Number
003
Particle
1.0-1.2um
Alloy Specification
Standard and Customized
1. Quick information
| Item name | tile cutter wheels |
| Material | 100% original tungsten carbide material |
| Quality grade recommended | K20 K10 |
| Surface treatment | general grinding,polishing,mirror polishing |
| Dimensions | As dimension table below |
| Export port | Guangzhou,Shenzhen,Shanghai,Ningbo |
| MOQ | 200 pcs for existed specs,2000 pcs for nes specs |
| Samples | Available for free |
2.Main Dimensions
| Specs (mm) | Outer Diameter (mm) | Tolerance (mm) | Inner Diameter (mm) | Tolerance (mm) | Thickness (mm) | Tolerance (mm) | Cutting angle |
| Φ22*Φ6.0*4.7mm | 22.0 | +/-0.2mm | 6.0 | +0.1/-0 | 4.7 | 0/-0.1 | 90° 100° 110° 120° |
| Φ22*Φ6.0*2.0mm | 22.0 | +/-0.2mm | 6.0 | +0.1/-0 | 2.0 | 0/-0.1 | 90° 100° 110° 120° |
| Φ22*Φ10.5*3.0mm | 22.0 | +/-0.2mm | 10.5 | +0.1/-0 | 3.0 | 0/-0.1 | 90° 100° 110° 120° |
| Φ22*Φ10.5*2.0mm | 22.0 | +/-0.2mm | 10.5 | +0.1/-0 | 2.0 | 0/-0.1 | 90° 100° 110° 120° |
| Φ20*Φ5*3.0mm | 20.0 | +/-0.2mm | 5.0 | +0.1/-0 | 3.0 | 0/-0.1 | 90° 100° 110° 120° |
| Φ20*Φ5*2.0mm | 20.0 | +/-0.2mm | 5.0 | +0.1/-0 | 2.0 | 0/-0.1 | 90° 100° 110° 120° |
| Φ18*Φ6*3.0mm | 18.0 | +/-0.2mm | 6.0 | +0.1/-0 | 3.0 | 0/-0.1 | 90° 100° 110° 120° |
| Φ18*Φ6*1.5mm | 18.0 | +/-0.2mm | 6.0 | +0.1/-0 | 1.5 | 0/-0.1 | 90° 100° 110° 120° |
| Φ16*Φ6*3.0mm | 16.0 | +/-0.2mm | 6.0 | +0.1/-0 | 3.0 | 0/-0.1 | 90° 100° 110° 120° |
| Φ16*Φ6*1.5mm | 16.0 | +/-0.2mm | 6.0 | +0.1/-0 | 1.5 | 0/-0.1 | 90° 100° 110° 120° |
| Φ15*Φ6*2.0mm | 15.0 | +/-0.2mm | 6.0 | +0.1/-0 | 2.0 | 0/-0.1 | 90° 100° 110° 120° |
| Φ15*Φ6*1.5mm | 15.0 | +/-0.2mm | 6.0 | +0.1/-0 | 1.5 | 0/-0.1 | 90° 100° 110° 120° |
| Φ12*Φ3*3.0mm | 12.0 | +/-0.2mm | 3.0 | +0.1/-0 | 3.0 | 0/-0.1 | 90° 100° 110° 120° |
| Φ10*Φ4*3.0mm | 10.0 | +/-0.2mm | 4.0 | +0.1/-0 | 3.0 | 0/-0.1 | 90° 100° 110° 120° |
