NI PXI-5651 Signal Generator Module

Product Introduction

NI PXI-5651 is a high-performance RF signal generator module from National Instruments (NI), belonging to the PXI series of products. This module provides a wide range of frequencies, high-precision signal generation and rich modulation functions, and is suitable for RF testing, communication system verification, radio spectrum analysis and other applications. The following is general product information about the NI PXI-5651 module:

Wide frequency range: The PXI-5651 module has a wide frequency range, covering frequency areas from 10 MHz to 6 GHz. It supports multiple standard RF frequency bands and provides high-precision frequency regulation and stability.

High precision and stability: This module has the characteristics of high precision and stability, which can achieve accurate RF signal generation. It adopts a high-precision frequency synthesizer and a stable clock source to provide precise frequency and phase control.

Multiple modulation functions: The PXI-5651 module supports multiple modulation methods, such as frequency modulation (FM), amplitude modulation (AM), phase shift keying (PSK), orthogonal amplitude modulation (QAM), etc. It provides flexible modulation parameter settings and modulation signal generation, which can meet the needs of different application scenarios.

High dynamic range and low harmonic distortion: The module has the ability to provide high-quality RF signals with high dynamic range and low harmonic distortion. It adopts high-performance digital signal processing and filtering technology to maintain the cleanliness and accuracy of the output signal.

External triggering and synchronization operation: The PXI-5651 module supports external triggering and synchronization operation functions, and can perform precise clock synchronization with other devices. This is very useful for multi device collaborative work and complex system integration.

Software support and development tools: The PXI-5651 module can be used in conjunction with NI's software platforms and development tools, such as LabVIEW, NI-RFmx, and NI-SystemLink. These tools provide rich functionality and easy-to-use interfaces, facilitating signal generation, modulation settings, and testing analysis for users

Product image display
