Mitsubishi Relay Module AJ65BTS-RPH

Mitsubishi Relay Module AJ65BTS-RPH

Spring clamp terminal block type relay module star wiring, extension of trunk length, spring clamp terminal block type AJ65BTS-RPH

Mitsubishi AJ65BTS-RPH product specifications

[Transmission speed] 156kbps/625kbps/2.5Mbps/5Mbps/10Mbps (optional)

The total number of connections between the main road and the branch road is,

The number of connection units used for the main unit.

[Number of connected units] 64 units

[Wiring location]

·Main line: * * * system (according to CC Link specifications)

·Branch line: connected to the branch end (section end)

[Number of connected segments]

·AJ65BTS-RPH: Section 2

·Combination of AJ65BTS-RPH and AJ65BT-RPT: 3 segments

·Combination of AJ65BTS-RPH, AJ65FBTA-RPH, AJ65SBT-RPS/RPG, and AJ65BT-RPI: 2 segments

The transmission speed varies depending on the transmission distance of each segment

[Area Code] No area code

[Number of occupied games] 0 games

[Terminal resistance] Main line 110 Ω/130 Ω (optional), branch line 110 Ω fixed (built-in)

[Withstand voltage] During 1 minute of AC500V between DC external terminal summary and grounding

[Insulation resistance] DC external terminal summary - DC 500V insulation resistance meter measures above 10 Ω between grounding

[External connection method] Spring clamp wiring terminal

[Unit Power Supply]

·Voltage: DC20.4~26.4V

·Current: 0.36mA (at TYP. DC24V)

[External dimensions H * W * D] 65 * 197.5 * 65.8mm

[Weight] 0.37kg
