Mitsubishi Q20UDHCPU universal CPU
Mitsubishi Q20UDHCPU input: 4 channels. Input: DC-10~10V, DC0~20mA.
Output (resolution): 0~4000, - 4000~4000, 0~12000, 0~16000, - 16000~16000 Mitsubishi q series plc.
Conversion speed: 500 μ S/1 channel.
Q20UDHCPU parameter description: 200K step multi-cPU high-speed communication, instruction processing speed is 9.5ns, USB/RS-232.
Detailed specification of Mitsubishi Q series CPU module Q20UDHCPU
[Control method] Stored program repeat operation
[Input/output mode] Refresh mode
[Program language]
Sequential control language: relay symbol language, logic symbol language, SEELSAP3 (SFC), MELSAP-L, function block and structured text (ST)
[Peripheral device connection port] USB, RS-232
[Memory card interface] Yes (SRAM/Flash/ATA card)
[Q20UDHCPU program capacity] 200K steps
[Q20UDHCPU processing speed (sequence control program instruction)]
LD X0：9.5ns
MOV D0 D1 19ns
[Constant scan] 0.5~2000ms (can be set in 0.5ms)
[Memory capacity]
Program memory: 800K
Memory card (RAM): The capacity of the installed memory card is 8MB
Memory card (ROM): installed memory card capacity (flash memory card: 4M bytes, ATA card: up to 32M bytes)
Standard ROM: 1280K
Standard RAM: 4096K
CPU shared memory: QCPU standard area is 8K, and high-speed communication area between multiple CPUs is 32K
[Number of stored files]
Program memory: 252
Memory card (RAM): 319 (when using Q3MEM-8MBS)
Memory card (ROM): Flash card 288, ATA card 511
Standard RAM: 4 (* * * file register, local software component, sampling tracking file, and module error record file respectively)
Standard ROM: 256
[Number of intelligent function module parameter settings] Initial setting 4096, 2048 at refresh
[Number of standard ROM allowed writes] 100000 times
[I/O soft component points] 8192 points (X/Y0~1FFF)
[Q20UDHCPU I/O points] 4096 points (X/Y0~FFF)
[Direct link software component] is used to directly access the software component of the link software component, * * * is used for MELSECNET/H
[Intelligent function module soft element] The soft element used to directly access the buffer memory of the intelligent function module.
[Latching range] L0 to 8191 (default 8192 point) (The locking range can be set for B, F, V, T, ST, C, D, W).
[RUN/PAUSE contact] One contact can be set in X0~1FFF for each of RUN and PAUSE.
[Allowable instantaneous power failure time] varies according to the type of power module.
[DC5V internal current consumption] 0.39A
[Boundary dimension H * W * D [mm]] 98 * 27.4 * 89.3
[Q20UDHCPU weight] 0.20kg
