New arrival 3M9735BX130 Cylinder block and head grinding machine

Name: New arrival 3M9735BX130 Cylinder block and head grinding machine
Price: Negotiable

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Description

Features:

Cylinder block and head grinding machine 3M9735BX150

It suits for grinding and milling all kinds of cylinder body and cover surface.

The spindle adopts high precision bearing the motor is fixed on the back of the machine which guarantee the spindle precision with high speed.

It adopts the plastic guide way running stable and flexible.

The feeding of work table adopts stepless speed changes devices, suits for processing all kinds of materials of work piece

Specification	3M9735Bx130	3M9735Bx150
Working table size	1300 x500mm	1500x500mm
Max working length	1300 mm	1500 mm
Max. width of grinding	350 mm	350 mm
Max height of grinding	800 mm	800 mm
The vertical moving distance of grinding head	60 mm	60 mm
The vertical moving distance of spindle box	800 mm	800 mm
Spindle speed	1400/700 r/min	1400/700 r/min
Transverse moving speed of working table	40-900 mm/min	40-900 mm/min
Overall dimensions(LxWxH)	2800x1050x1700 mm	3050x1050x1700 mm
Packing dimensions(LxWxH)	3100x1200x1850 mm	3350x1200x1850 mm
N.W. / G.W.	2800 / 3100 kg	3000 / 3300 kg

Standard accessories:

Parallel support, Grinding disk, Grinding wheel dresser, Cooling box, Grinding tiles & milling cutters, Wheel balance stand arbor.

Optional accessories:

Diamon dresser, Digital readout, Universal support.

Company Profile

Jingjiang Fuji Technology Co., Ltd.

Our company offers variety of products which can meet your multifarious demands. We adhere to the management principles of "quality first, customer first and credit-based" since the establishment of the company and always do our best to satisfy potential needs of our customers. Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with anirresistible force.
