Product Description

Machine Features:

1. The machine adopts the four-roller structure with the upper roller as the main drive, both upward and downward movement through hydraulic motors powered.
2. The lower roller makes vertial movements and imposes a force on the piston through the hydraulic oli in the hydraulic cylinder so as to clamp the plate tight.
3. Side rollers are arranged on the two sides of the lides of the lower roller, and make inclining movement along the guide rail, and provide drive through the screw, the nut,the worm and the leadscrew.
4. The advantage of the machine is that the preliminary bending and rolling of the top ends of the plates can be conducted on the same machine.
Model
Max.
Rolling Thickness
(mm)
Max.
Rolling Width
(mm)
Plate yield limit
(Mpa)
Min.Full Loading Dia.(mm)
Upper Roller Dia.(mm)
Bottom Roller Dia.(mm)
Side Roller
(mm)
Rolling Speed
(m/min)
Main Motor Power(kw)
W12-12*2000
12
2000
245
600
260
260
200
5.5
15
W12-12*2500
12
2500
245
800
280
260
220
5
15
W12-16*2000
16
2000
245
600
280
260
230
5
18.5
W12-16*2500
16
2500
245
800
300
280
260
4.5
22
W12-20*2000
20
2000
245
800
300
280
260
4.5
22
W12-20*2500
20
2500
245
900
350
330
300
4.5
22
W12-25*2500
25
2500
245
1000
400
380
320
4.5
30
W12-20*3000
20
3000
245
1100
400
380
320
4
30
W12-25*3000
25
3000
245
1200
400
400
340
4
37
W12-30*3000
30
3000
245
1300
460
440
360
4
37
W12-40*3000
40
3000
245
1300
540
520
420
3
45
W12-50*3000
50
3000
245
1600
620
580
480
3
55
W12-60*3000
60
3000
245
2000
680
620
520
3
55
Detailed Images
Company Profile
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.

Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides,we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.

Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.

Q4:What’s the MOQ?
A4:One set only.

Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.

Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.

Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
