HP30 HP50 HP100 30 Ton 50 Ton 100 Ton Hydraulic Press Machine for Sale
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
W11 Series 3-roller Mechanical Bending MachineNegotiableMOQ: 1 -
WC67Y-125/3200 China Cheap Price Hydraulic Press MachineNegotiableMOQ: 1
-
QC12Y 6X3200 QC12Y Sheet Hydraulic Shearing Machine PriceNegotiableMOQ: 1
-
Q35Y Hydraulic Punching and Shearing Machine With Competitive PriceNegotiableMOQ: 1
-
Q35Y-20 Cheap Hydraulic Punching and Shearing Machine for Metal WorkingNegotiableMOQ: 1
Products Recommend
Products Show
Press Machine Main Features:
The machine supplied oil by Italy CNK and CBZ pump. It could save 60% energy compared with the traditional model. The efficiency increased to 2-3 times. It takes the advantages of small volume, high pressure, simple structure and light weight.
With the function of brake.
With adjustable worktable.
Extremely torsion-proof steel weldment.
Reliable high accurate hydraulic system.
Hydraulic press unclude replaceable toptools.
V-block and support table with stops.
Table can be tilted through a chain driven by the main cylinder.
The machine supplied oil by Italy CNK and CBZ pump. It could save 60% energy compared with the traditional model. The efficiency increased to 2-3 times. It takes the advantages of small volume, high pressure, simple structure and light weight.
With the function of brake.
With adjustable worktable.
Extremely torsion-proof steel weldment.
Reliable high accurate hydraulic system.
Hydraulic press unclude replaceable toptools.
V-block and support table with stops.
Table can be tilted through a chain driven by the main cylinder.
Model |
Capacity |
Pressure |
Travel |
Table size |
Dimension |
Weight |
HP-10 |
100kn |
25mpa |
200mm+200mm |
260x300mm |
1000x450x1200mm |
220kgs |
HP-20 |
200kn |
25mpa |
200mm+250mm |
260x300mm |
1160x550x1500mm |
320kgs |
HP-30 |
300kn |
25mpa |
200mm+270mm |
300x400mm |
1160x550x1600mm |
420kgs |
HP-50 |
500kn |
25mpa |
220mm+405mm |
480x360mm |
1500x650x1950mm |
980kgs |
HP-63 |
630kn |
30mpa |
220mm+405mm |
400x500mm |
1500x650x1950mm |
1020kgs |
HP-100 |
1000kn |
30mpa |
220mm+405mm |
440x980mm |
1730x730x2200mm+730x630x960mm |
1220kgs |
HP-150 |
1500kn |
30mpa |
220mm+405mm |
440x980mm |
1730x730x2200mm+730x630x960mm |
1350kgs |
HP-200 |
2000kn |
30mpa |
300mm+405mm |
500x980mm |
1800x800x2200mm+830x730x1260mm |
2200kgs |
HP-250 |
2500kn |
30mpa |
300mm+405mm |
500x980mm |
1800x800x2250mm+830x730x1260mm |
2400kgs |
Detailed Images
Company Profile
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
