M1320HX500 800mm Cylindrical Grinding Machine for External Grinding
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Universal Cylindrical Grinding Machine M1420H/FX500 for Internal and External GrindingNegotiableMOQ: 1 -
New Arrival M1332B 1000mm 1500mm Cheap Grinder Universal Cylindrical Grinding MachineNegotiableMOQ: 1
-
M1432B 1000mm 1500mm Universal Cylindrical Grinding Machine for Precision Grinding PurposeNegotiableMOQ: 1
-
M1350B Cylindrical Grinding Machine for External Grinding FuntionNegotiableMOQ: 1
-
Cylindrical Grinder M1450B Universal Cylindrical Grinding MachineNegotiableMOQ: 1
Product Description
M1320HX500 800mm cylindrical Grinding Machine for external grinding
Description |
unit |
M1320H×500 |
M1320H×800 |
External grinding diameters |
mm |
Φ8 ~200 |
Φ8 ~200 |
Center height |
mm |
135 |
135 |
Max.travel of table |
mm |
650 |
950 |
Hydraulic traverse sdeeds |
m/min |
0.1~4 |
0.1~4 |
piece weight |
kg |
50 |
50 |
Grinding length External |
mm |
500 |
800 |
Swivel range of worktable |
. |
﹣5~+9° |
﹣3~+7° |
Max peripheral speed of grinding wheel |
m/s |
38 |
38 |
Externalwheef size |
mm |
MaxΦ400×50×Φ203 |
MinΦ280×50×Φ203 |
Workhead and tailstock center |
NO.4 |
NO.4 |
|
Machine motor power |
kw |
5.625 |
5.625 |
Overall dimensions(L×W×H) |
mm |
2500×1600×1500 |
3000×1600×1500 |
Machine weight |
kg |
2500 |
3000 |
Machine Accessories
Standard Accessories
Coolant tank
Grinding wheel dresser
Wheel balancing mandrel
Driving dog
Carbide-tipped center
Supportiron
Open type steady rest
Wheel flange
3-jaw chuck
Chuck base
Quill shaft for internal grinding
Grinding wheel dresser
Wheel balancing mandrel
Driving dog
Carbide-tipped center
Supportiron
Open type steady rest
Wheel flange
3-jaw chuck
Chuck base
Quill shaft for internal grinding
Optional Accessories
Wheel balancing stand
Radius dresser
Closed type steady rest
Radius dresser
Closed type steady rest
Machine Details
Company Profile
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
