Product Description
6'' x 18 '' Surface Grinding Machine:
Manual grinder for metal;
Processing stability is very high;
Good performance.
Specification |
Unit |
M 618 |
Table maximum cutting area (LxWxH) |
mm |
500x190x335 |
Max. Grinding Length |
mm |
500 |
Max. Grinding width |
mm |
190 |
Distance From Table Surface To Spindle Center |
mm |
335 |
Maximum work load |
Kg |
200 |
Table size |
mm |
460x180 |
Number of T -Slot |
mmxn |
14x1 |
Front and rear wheel feed |
mm |
0.02/Graduation2.5/revolution |
On the hand wheel feed |
mm |
0.01/Graduation1.25/revolution |
Wheel Size(dia×width×bore) |
mm |
180×13×31.75 |
Spindle speed |
rpm |
2850 |
Spindle motor |
Kw |
1.1 |
Cooling pump |
Kw |
0.4 |
Packing Size (LxWxH) |
mm |
1240x1080x1680 |
Machine pics.
