7705 2101-2402025 Rear Axle Gearbox Bearing for LADA 1200-1500 LADA 1200-1600 LADA 2107
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Machinery Repair Shops Profession 7705 2101-2402025 Rear Axle Bearings For Lada Nova Lada Oka Lada ZhiguliNegotiableMOQ: 1 -
Creative Design Single Row 7705 2101-2402025 Rear Axle Bearings For Lada Kalinka Lada LaikaNegotiableMOQ: 1
-
2101-2403036 7707y Tapered Roller Bearing for VAZ 2101-2107 Car Rear Differential Left and Right SidesNegotiableMOQ: 1
-
2101-2402025 Rear Axle Gearbox Bearing for VAZ-2101-07 Front (7705) Russia CarsNegotiableMOQ: 1
-
Hot Selling 2101-2403036 7707 Tapered Roller Bearing for Vaz 2121 4x4 Front and Rear AxlesNegotiableMOQ: 1
Specification
Product name | 7705 2101-2402025 Rear axle gearbox bearing for LADA 1200-1500 LADA 1200-1600 LADA 2107 |
Usage | Rear axle gearbox bearing |
Size | 28*67*20mm |
Car Make | LADA 1200-1500 LADA 1200-1600 LADA 2107 |
OE NO. | 7705 2101-2402025 |
Place of Origin | China |
Brand Name | VLBG |
Model Number | 2101-2402025 |
Warranty | 24Months |
Inner diameter | 28MM |
Outside diameter | 67MM |
Height | 20MM |
Bearing type | Friction bearings |
Certificate | ISO9001/TS16949 |
Roller body material | SHX15 |
Weight | 0.379 |
Number of rolling bodies | 15 |
Standard | TU 37.006.170-90 |
Roller length | 14.96 |
Type of perceived loads | Radial thrust |
Roller Body diameter | 7.5 |
bearing diagram 7705
Number of rollers - 15 pcs.;
Roller dimensions - 7.5 / 8.6x14.96 mm;
Dynamic lifting capacity - 60 kN;
Static lifting capacity - 72 kN;
Inner diameter - 28 mm;
Outside diameter - 67 mm;
Width - 20.5 mm;
Weight - 0.379 kg;
The maximum rated speed is 8000 rpm.
Bearing 7705 is intended for use only in VAZ cars - "classic" (models 2101, 2102, 2103, 2104, 2105, 2106, 2107) (rear axle) and Niva 2121 4x4 (front and rear axles), where it is installed along with the bearing 7707 . It has practically no other scope.
BEARING 7705A-6 GEARS OF THE DRIVING FRONT AND REAR AXLES (FRONT SUPPORT) VPZ
Applicability:
VAZ-2101, 21011, 21012, 21013, 21014, VAZ-2102, 21022, 21023, 21024, VAZ-2103, 21031, 21032, 21033, 21034, 21035, VAZ-2104, 21043, 21047, VAZ-2105, 21051 , 21053, VAZ-2106, 21061, 21063, 21065, VAZ-2107, VAZ-2120 NADEZHDA, VAZ-2121 NIVA, VAZ-21213 NIVA, VAZ-21213i NIVA (injector), VAZ-21214 LADA 4x4, VAZ-2123 NIVA CHEVROLET, VAZ-2131 NIVA
The bearing is roller, angular contact, tapered (or this type is also called "with tapered rollers"), single-row, basic design, wide series. The degree of accuracy is usually zero, which does not play a special role. A modification is made with a steel cage (letter U or A to the right of the number) or polyamide (the letter E is additionally indicated). Also, bearings can be produced with increased requirements for the level of emitted noise (the presence of the letter Ш in the number). Contact angle? in this type it is from 10 to 18 °. With an increase in the taper of the outer ring, the axial load capacity increases and the radial load decreases. For double-sided shaft fixation, these rolling bearings must be installed in pairs.
In Russia, this type is produced at the Samara Bearing Plant - 9 GPPs, as well as at the Volzhsky Bearing Plant (formerly 15 GPPs, the products are now labeled VPZ). In terms of price, the second is preferable, and in terms of quality it is not inferior. In auto parts stores, very often only Chinese Craft are on sale, which are cheap, but do not differ in reliability.
Bearing 7705 is intended for use only in VAZ cars - "classic" (models 2101, 2102, 2103, 2104, 2105, 2106, 2107) (rear axle) and Niva 2121 4x4 (front and rear axles), where it is installed along with the bearing 7707. He practically has no other sphere of application.
This standard size does not have an exact foreign analogue.
