Home > Industrial Equipment & Components > Bearing > Taper Roller Bearing > 7805 2101-3103020 6-7805 U Front Wheel Hub Bearings for Car VAZ-2101 Car VAZ-2102 VAZ-2103
7805 2101-3103020 6-7805 U Front Wheel Hub Bearings for Car VAZ-2101 Car VAZ-2102 VAZ-2103
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Tapered Roller Bearing 7705 of the Front Axle Gearbox VAZ 2121 Niva, RZM VAZ-2101 2101-2402025NegotiableMOQ: 1 -
2121-3103020 6-2007108A 32008 Tapered Roller Bearing Size 40x68x19 mm for Off-road Passenger VAZ-2121 Front Wheel HubsNegotiableMOQ: 1
-
Factory Price 32008 2007108 Taper Roller Bearing for EcuadorNegotiableMOQ: 1
-
Russian Car Lada VAZ 2101 2102 2103 2104 Rear Axle Use Tapered Roller Bearing 2101-2402041 7807 34.938x73.03x26.987 for SellingNegotiableMOQ: 1
-
Russian Market Hot Selling VAZ 2103 2104 2105 2106 2107 Rear Axle Wheel Bearing Tapered Roller Bearing 2101-2402041 7807NegotiableMOQ: 1
Specification
Product name |
7805 2101-3103020 6-7805 U front wheel hub bearings for Car VAZ-2101 Car VAZ-2102 VAZ-2103 |
Usage |
Single-row Taper Roller Bearing |
Size |
26x57,15x17,462 |
Car Make |
VAZ-2101 VAZ-2102 VAZ-2103 VAZ-2105 VAZ-2106 VAZ-2107 VAZ-21213 VAZ-2123 |
Place of Origin |
China |
Brand Name |
VLBG |
Model Number |
7805 2101-3103020 6-7805 U |
Warranty |
24Months |
Inner diameter |
26MM |
Outside diameter |
57.15MM |
Height |
17.462MM |
Bearing type |
Friction bearings |
Certificate |
ISO9001/TS16949 |
Roller body material |
SHX15 |
Weight |
0.225 |
Number of rolling bodies |
14 |
Standard |
TU 37.006.170-90 |
Roller length |
12.4 |
Type of perceived loads |
Radial thrust |
Roller Body diameter |
6.3 |
Bearing 7805 size 26x57,15x17,462
Tapered roller bearings 7805designed for the simultaneous perception of axial and axial loads, which allows you to expand the scope of its application and significantly simplify the design of the supporting units of mechanisms and equipment. In application Angular contact tapered roller bearing 7805 reduces the requirements for alignment, which is very important in the manufacture of products, especially large-sized ones. Mounting a single bearing provides the ability to take a radial load together with an axial load acting in one direction (paired installation, with axial bidirectional). Angular contact tapered roller bearing 7805 has a wide range of applications: in general machine building equipment, in transmissions of tractor and automotive equipment, in wheel hubs, in metalworking machines.
Bearing specifications 7805
Inner diameter - 26 mm;
Outside diameter - 57.15 mm;
Width - 17.462 mm;
Weight - 0.226 kg;
The number of rollers in the bearing - 14 pcs .;
Roller dimensions - 6.3 / 7.06x12.4 mm;
Dynamic lifting capacity - 37.8 kN;
Static lifting capacity - 42.8 kN;
The maximum rated speed is 8000 rpm.
Bearing 7805
The bearing is roller, angular contact, tapered (or this type is also called "with tapered rollers"), single-row, basic design, wide series. This design allows it to be used as hub bearings ( front VAZ bearings ). Manufactured according to the sixth degree of accuracy. Contact angle? in this type it is from 10 to 18 °. With an increase in the taper of the outer ring, the axial load capacity increases and the radial load decreases. During operation, one should avoid very small and vice versa, excessively large clearances, which can lead to an unacceptable increase in the operating temperature and even destruction of bearing parts.
The production of this product is carried out at 15 GPPs (Volzhsky, VPZ marking) and 9 GPPs (Samara, SPZ-GROUP marking). Since the front hub bearings experience high loads, it is not recommended to buy this type with a different marking, since in this case there is a high probability of their premature failure, which can also entail more serious consequences if the car is on the move. This is especially true of low-quality Chinese bearings, which attract buyers with their cheapness (Craft, KG, AMS).
Bearing 7805, along with bearing 7804, is the front hub bearing of VAZ models from 2101 to 2107 (unlike it, it is installed in an internal support).
The imported analogue of this type of roller bearing is designated according to the international nomenclature - 639154
7805
Russian roller bearing 7805 (2101-3103020) VAZ 2101 front hub bearing
Bearing 7805 size 26x57,15x17,462
6-7805 U front wheel hub bearings for Car VAZ-2101 Car VAZ-2102 VAZ-2103
6-7805 U 2101-3103020 front wheel hub bearings for Passenger car VAZ-2105 VAZ-2106 VAZ-2107
6-7805U Car VAZ-2101-2107 front wheel hubs (internal support)
6-7805 U Car VAZ-2101-2108 Front wheel hub (78047805) / Rear hub (78047205)
6-7805 U Car VAZ-2121 Niva Front wheel hub (78047805) / Rear hub (78047205)
4T-15579X / 15520 PLC64-11 15579X / 15520
