water drill bit carbide cemented carbide coal drill bit drill bit tungsten carbide scrap
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
cemented carbide button inserts cemented carbide mining bit cemented carbide welding inserts
-
tungsten carbide indexable turning insert tungsten carbide threading inserts carbide thread milling insert
-
cbn/pcd inserts for cutting tool cut tools cnc tungsten carbide milling insert
-
ceramic bar / rod / tube
-
petroleum drill bits drill rod sizes pdc cutter bits
-
cemented diy scoring wheel for glass and ceramics cutter wheel glaze YG6 tile cutter
Product Description
ISO solid carbide rod
specification:
We are the only one manufactory which can provide the cemented carbide rods with one straight cooland hold in China right now.
The Cemented carbide rods can be used for making varioius drill bits, automobile special cutter, printed circuit board ,special cutters, engine special cutters, horologe,processing special cutters, integral vertical milling cutter, graver and etc.
the cemented carbide rods can also be used for making of cemented carbide stamping head, core bar and perforation tools.
Besides, The cemented carbide rods are used for cutting aluminum alloy , cast iron , stainless steel , refractory alloy steel ,nickel-based alloy , titanium alloy and non-ferrous metal , various carbide grades with stable properties have been widely recongnized by worldwide tool makers. We can produced the ungrounded and grounded cemented carbide rods.
Grades,composition and properties:
| GRADE | YG6X | ZK10UF | ZK20UF | ZK20SF | ZK30UF | ZK31UF | ZK30SF | ZK40SF |
| Chemical composition | 6%Co-WC | 6%Co-WC | 8%Co-WC | 8%Co-WC | 10%Co-WC | 10%Co-WC | 10%Co-WC | 12%Co-WC |
| ISO GRADE | K10 | K05-K15 | K20-K30 | K20-K40 | K20-K30 | K20-K30 | K20-K40 | K40-K50 |
| Density(g/cm3) | 14.9 | 14.85 | 14.65 | 14.45 | 14.45 | 14.4 | 14.4 | 14.1 |
| Hardness(HRA) | 92.5 | 93 | 92.6 | 92.8 | 92 | 91.5 | 92.5 | 92.1 |
| Strength(N/mm) | 2500 | 2800 | 3200 | 3400 | 3500 | 4000 | 3600 | 3400 |
| WC average grain size | 1.0μm | 0.6μm | 0.6μm | 0.4-0.5μm | 0.6μm | 0.7μm | 0.4-0.5μm | 0.4-0.5μm |
SIZE:
| Ø 1.0 h6 x 330+0.5 mm | Ø 1.0 +0.3 x 330+0.5 mm | Ø 1.3 +0.3 x 330+0.5 mm | Ø 1.7 +0.3 x 330+0.5 mm |
| Ø 2.0 h6 x 330+0.5 mm | Ø 2.0 +0.3 x 330+0.5 mm | Ø 2.3 +0.3 x 330+0.5 mm | Ø 2.7 +0.3 x 330+0.5 mm |
| Ø 3.0 h6 x 330+0.5 mm | Ø 3.0 +0.3 x 330+0.5 mm | Ø 3.3 +0.3 x 330+0.5 mm | Ø 3.7 +0.3 x 330+0.5 mm |
| Ø 4.0 h6 x 330+0.5 mm | Ø 4.0 +0.3 x 330+0.5 mm | Ø 4.3 +0.3 x 330+0.5 mm | Ø 4.7 +0.3 x 330+0.5 mm |
| Ø 5.0 h6 x 330+0.5 mm | Ø 5.0 +0.3 x 330+0.5 mm | Ø 5.3 +0.3 x 330+0.5 mm | Ø 5.7 +0.3 x 330+0.5 mm |
| Ø 6.0 h6 x 330+0.5 mm | Ø 6.0 +0.3 x 330+0.5 mm | Ø 6.3 +0.3 x 330+0.5 mm | Ø 6.7 +0.3 x 330+0.5 mm |
| Ø 7.0 h6 x 330+0.5 mm | Ø 7.0 +0.3 x 330+0.5 mm | Ø 7.3 +0.3 x 330+0.5 mm | Ø 7.7 +0.3 x 330+0.5 mm |
| Ø 8.0 h6 x 330+0.5 mm | Ø 8.0 +0.3 x 330+0.5 mm | Ø 8.3 +0.3 x 330+0.5 mm | Ø 8.7 +0.3 x 330+0.5 mm |
| Ø 9.0 h6 x 330+0.5 mm | Ø 9.0 +0.3 x 330+0.5 mm | Ø 9.3 +0.3 x 330+0.5 mm | Ø 9.7 +0.3 x 330+0.5 mm |
| Ø 10.0 h6 x 330+0.5 mm | Ø 10.0 +0.3 x 330+0.5 mm | Ø 10.3 +0.3 x 330+0.5 mm | Ø 10.7 +0.3 x 330+0.5 mm |
| Ø 11.0 h6 x 330+0.5 mm | Ø 11.0 +0.3 x 330+0.5 mm | Ø 11.3 +0.3 x 330+0.5 mm | Ø 11.7 +0.3 x 330+0.5 mm |
| Ø 12.0 h6 x 330+0.5 mm | Ø 12.0 +0.3 x 330+0.5 mm | Ø 12.3 +0.3 x 330+0.5 mm | Ø 12.7 +0.3 x 330+0.5 mm |
| Ø 13.0 h6 x 330+0.5 mm | Ø 13.0 +0.3 x 330+0.5 mm | Ø 13.3 +0.3 x 330+0.5 mm | Ø 13.7 +0.3 x 330+0.5 mm |
| Ø 14.0 h6 x 330+0.5 mm | Ø 14.0 +0.3 x 330+0.5 mm | Ø 14.3 +0.3 x 330+0.5 mm | Ø 14.7 +0.3 x 330+0.5 mm |
| Ø 15.0 h6 x 330+0.5 mm | Ø 15.0 +0.3 x 330+0.5 mm | Ø 15.3 +0.3 x 330+0.5 mm | Ø 15.7 +0.3 x 330+0.5 mm |
| Ø 16.0 h6 x 330+0.5 mm | Ø 16.0 +0.3 x 330+0.5 mm | Ø 16.3 +0.3 x 330+0.5 mm | Ø 16.7 +0.3 x 330+0.5 mm |
| Ø 17.0 h6 x 330+0.5 mm | Ø 17.0 +0.3 x 330+0.5 mm | Ø 17.3 +0.3 x 330+0.5 mm | Ø 17.7 +0.3 x 330+0.5 mm |
| Ø 18.0 h6 x 330+0.5 mm | Ø 18.0 +0.3 x 330+0.5 mm | Ø 18.3 +0.3 x 330+0.5 mm | Ø 18.7 +0.3 x 330+0.5 mm |
| Ø 19.0 h6 x 330+0.5 mm | Ø 19.0 +0.3 x 330+0.5 mm | Ø 19.3 +0.3 x 330+0.5 mm | Ø 19.7 +0.3 x 330+0.5 mm |
| Ø 20.0 h6 x 330+0.5 mm | Ø 20.0 +0.3 x 330+0.5 mm | Ø 20.3 +0.3 x 330+0.5 mm | Ø 20.7 +0.3 x 330+0.5 mm |
| Ø 21.0 h6 x 330+0.5 mm | Ø 21.0 +0.3 x 330+0.5 mm | Ø 21.3 +0.3 x 330+0.5 mm | Ø 21.7 +0.3 x 330+0.5 mm |
| Ø 22.0 h6 x 330+0.5 mm | Ø 22.0 +0.3 x 330+0.5 mm | Ø 22.3 +0.3 x 330+0.5 mm | Ø 22.7 +0.3 x 330+0.5 mm |
| Ø 23.0 h6 x 330+0.5 mm | Ø 23.0 +0.3 x 330+0.5 mm | Ø 23.3 +0.3 x 330+0.5 mm | Ø 23.7 +0.3 x 330+0.5 mm |
| Ø 24.0 h6 x 330+0.5 mm | Ø 24.0 +0.3 x 330+0.5 mm | Ø 24.3 +0.3 x 330+0.5 mm | Ø 24.7 +0.3 x 330+0.5 mm |
| Ø 25.0 h6 x 330+0.5 mm | Ø 25.0 +0.3 x 330+0.5 mm | Ø 25.3 +0.3 x 330+0.5 mm | Ø 25.7 +0.3 x 330+0.5 mm |
Factory photo:
Qualiy Index of National Test Standard
Analytica testig laboratory:
High purity raw mteial:Tungsten cabide powder and Cobalt mterial
High-precision technical equipment:1
Photo 2
Photo 3
Photo 4
Photo 5
Photo 6
13-levels quality control systerm:
Packing and shipment:
SAFETY SALE SERVICE:
