Petroleum Drill Bits Drill Rod Sizes Pdc Cutter Bits photo-4
Petroleum Drill Bits Drill Rod Sizes Pdc Cutter Bits photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Agent
Year Established:
2013
Annual Export Value:
US$50 Million - US$100 Million
Contact Supplier Request Quote Chat Now
Hunan Hastion Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us



ISO solid carbide rod

specification:



We are the only one manufactory which can provide the cemented carbide rods with one straight cooland hold in China right now.



The Cemented carbide rods can be used for making varioius drill bits, automobile special cutter, printed circuit board ,special cutters, engine special cutters, horologe,processing special cutters, integral vertical milling cutter, graver and etc.


the cemented carbide rods can also be used for making of cemented carbide stamping head, core bar and perforation tools.


Besides, The cemented carbide rods are used for cutting aluminum alloy , cast iron , stainless steel , refractory alloy steel ,nickel-based alloy , titanium alloy and non-ferrous metal , various carbide grades with stable properties have been widely recongnized by worldwide tool makers. We can produced the ungrounded and grounded cemented carbide rods.



Grades,composition and properties:

GRADE YG6X ZK10UF ZK20UF ZK20SF ZK30UF ZK31UF ZK30SF ZK40SF
Chemical composition 6%Co-WC 6%Co-WC 8%Co-WC 8%Co-WC 10%Co-WC 10%Co-WC 10%Co-WC 12%Co-WC
ISO GRADE K10 K05-K15 K20-K30 K20-K40 K20-K30 K20-K30 K20-K40 K40-K50
Density(g/cm3) 14.9 14.85 14.65 14.45 14.45 14.4 14.4 14.1
Hardness(HRA) 92.5 93 92.6 92.8 92 91.5 92.5 92.1
Strength(N/mm) 2500 2800 3200 3400 3500 4000 3600 3400
WC average grain size 1.0μm 0.6μm 0.6μm 0.4-0.5μm 0.6μm 0.7μm 0.4-0.5μm 0.4-0.5μm



SIZE:

Ø 1.0 h6 x 330+0.5 mm Ø 1.0 +0.3 x 330+0.5 mm Ø 1.3 +0.3 x 330+0.5 mm Ø 1.7 +0.3 x 330+0.5 mm
Ø 2.0 h6 x 330+0.5 mm Ø 2.0 +0.3 x 330+0.5 mm Ø 2.3 +0.3 x 330+0.5 mm Ø 2.7 +0.3 x 330+0.5 mm
Ø 3.0 h6 x 330+0.5 mm Ø 3.0 +0.3 x 330+0.5 mm Ø 3.3 +0.3 x 330+0.5 mm Ø 3.7 +0.3 x 330+0.5 mm
Ø 4.0 h6 x 330+0.5 mm Ø 4.0 +0.3 x 330+0.5 mm Ø 4.3 +0.3 x 330+0.5 mm Ø 4.7 +0.3 x 330+0.5 mm
Ø 5.0 h6 x 330+0.5 mm Ø 5.0 +0.3 x 330+0.5 mm Ø 5.3 +0.3 x 330+0.5 mm Ø 5.7 +0.3 x 330+0.5 mm
Ø 6.0 h6 x 330+0.5 mm Ø 6.0 +0.3 x 330+0.5 mm Ø 6.3 +0.3 x 330+0.5 mm Ø 6.7 +0.3 x 330+0.5 mm
Ø 7.0 h6 x 330+0.5 mm Ø 7.0 +0.3 x 330+0.5 mm Ø 7.3 +0.3 x 330+0.5 mm Ø 7.7 +0.3 x 330+0.5 mm
Ø 8.0 h6 x 330+0.5 mm Ø 8.0 +0.3 x 330+0.5 mm Ø 8.3 +0.3 x 330+0.5 mm Ø 8.7 +0.3 x 330+0.5 mm
Ø 9.0 h6 x 330+0.5 mm Ø 9.0 +0.3 x 330+0.5 mm Ø 9.3 +0.3 x 330+0.5 mm Ø 9.7 +0.3 x 330+0.5 mm
Ø 10.0 h6 x 330+0.5 mm Ø 10.0 +0.3 x 330+0.5 mm Ø 10.3 +0.3 x 330+0.5 mm Ø 10.7 +0.3 x 330+0.5 mm
Ø 11.0 h6 x 330+0.5 mm Ø 11.0 +0.3 x 330+0.5 mm Ø 11.3 +0.3 x 330+0.5 mm Ø 11.7 +0.3 x 330+0.5 mm
Ø 12.0 h6 x 330+0.5 mm Ø 12.0 +0.3 x 330+0.5 mm Ø 12.3 +0.3 x 330+0.5 mm Ø 12.7 +0.3 x 330+0.5 mm
Ø 13.0 h6 x 330+0.5 mm Ø 13.0 +0.3 x 330+0.5 mm Ø 13.3 +0.3 x 330+0.5 mm Ø 13.7 +0.3 x 330+0.5 mm
Ø 14.0 h6 x 330+0.5 mm Ø 14.0 +0.3 x 330+0.5 mm Ø 14.3 +0.3 x 330+0.5 mm Ø 14.7 +0.3 x 330+0.5 mm
Ø 15.0 h6 x 330+0.5 mm Ø 15.0 +0.3 x 330+0.5 mm Ø 15.3 +0.3 x 330+0.5 mm Ø 15.7 +0.3 x 330+0.5 mm
Ø 16.0 h6 x 330+0.5 mm Ø 16.0 +0.3 x 330+0.5 mm Ø 16.3 +0.3 x 330+0.5 mm Ø 16.7 +0.3 x 330+0.5 mm
Ø 17.0 h6 x 330+0.5 mm Ø 17.0 +0.3 x 330+0.5 mm Ø 17.3 +0.3 x 330+0.5 mm Ø 17.7 +0.3 x 330+0.5 mm
Ø 18.0 h6 x 330+0.5 mm Ø 18.0 +0.3 x 330+0.5 mm Ø 18.3 +0.3 x 330+0.5 mm Ø 18.7 +0.3 x 330+0.5 mm
Ø 19.0 h6 x 330+0.5 mm Ø 19.0 +0.3 x 330+0.5 mm Ø 19.3 +0.3 x 330+0.5 mm Ø 19.7 +0.3 x 330+0.5 mm
Ø 20.0 h6 x 330+0.5 mm Ø 20.0 +0.3 x 330+0.5 mm Ø 20.3 +0.3 x 330+0.5 mm Ø 20.7 +0.3 x 330+0.5 mm
Ø 21.0 h6 x 330+0.5 mm Ø 21.0 +0.3 x 330+0.5 mm Ø 21.3 +0.3 x 330+0.5 mm Ø 21.7 +0.3 x 330+0.5 mm
Ø 22.0 h6 x 330+0.5 mm Ø 22.0 +0.3 x 330+0.5 mm Ø 22.3 +0.3 x 330+0.5 mm Ø 22.7 +0.3 x 330+0.5 mm
Ø 23.0 h6 x 330+0.5 mm Ø 23.0 +0.3 x 330+0.5 mm Ø 23.3 +0.3 x 330+0.5 mm Ø 23.7 +0.3 x 330+0.5 mm
Ø 24.0 h6 x 330+0.5 mm Ø 24.0 +0.3 x 330+0.5 mm Ø 24.3 +0.3 x 330+0.5 mm Ø 24.7 +0.3 x 330+0.5 mm
Ø 25.0 h6 x 330+0.5 mm Ø 25.0 +0.3 x 330+0.5 mm Ø 25.3 +0.3 x 330+0.5 mm Ø 25.7 +0.3 x 330+0.5 mm



Factory photo:

petroleum drill bits drill rod sizes pdc cutter bits











Qualiy Index of National Test Standard



petroleum drill bits drill rod sizes pdc cutter bits



Analytica testig laboratory:

 petroleum drill bits drill rod sizes pdc cutter bits







 High purity raw mteial:Tungsten cabide powder and Cobalt mterial



petroleum drill bits drill rod sizes pdc cutter bits



 High-precision technical equipment:1

 petroleum drill bits drill rod sizes pdc cutter bits





Photo 2

petroleum drill bits drill rod sizes pdc cutter bits





  Photo 3

petroleum drill bits drill rod sizes pdc cutter bits





  Photo 4

petroleum drill bits drill rod sizes pdc cutter bits







  Photo 5

petroleum drill bits drill rod sizes pdc cutter bits





  Photo 6

petroleum drill bits drill rod sizes pdc cutter bits





13-levels quality control systerm:

petroleum drill bits drill rod sizes pdc cutter bits







Packing and shipment:

petroleum drill bits drill rod sizes pdc cutter bits







The best describe is Comments from users:

 petroleum drill bits drill rod sizes pdc cutter bits



SAFETY SALE SERVICE:



petroleum drill bits drill rod sizes pdc cutter bits





Any questions about our products,please just email to me by lula at ,Mobile:+86-13677350915,  Mobile:+86-13647315326,  I would quote the most favorable price for you.
