CE approved HVS-1000A Digital Display Micro Vickers Hardness Tester/Hardness Testing Machine

Applications:

This tester is a new type of product which is equipped with new features such as RS232 interface, automatic turret, high level LCD display etc. It is especially suited for measuring the Microhardness of thin, small metal test pieces and the brittle materials

Specifications:

Measuring range: 5-3000HV

Test force: 0.09807, 0.2452, 0.4904, 0.9807, 1.961, 2.942, 4.904, 9.807N

(10, 25, 50, 100, 200, 300, 500, 1000gf)

Hardness scale: HV0.01, HV0.025, HV0.05, HV0.1, HV0.2, HV0.3, HV0.5, HV1

Magnifications of the measuring system: 400X (measuring),   100X (observing)

Min. scale value of the optical micrometer: 0.025μm

Measuring range: 200μm

Max. height of test piece: 75mm

Depth of throat: 110mm

Power supply: 220V AC or 110V AC, 50 or 60Hz

Dimensions: 470 x 320 x 500mm

Weight: approx. 50kg

Send an inquiry for this product

Details :

1. Delivery date: 7 days after receiving payment

2. Payment terms: T/T, 100% before shipment.

3. Packages: Plywood Cases
