Features:
u Large screen(240*320 Color LCD), showing all functions and parameters.
u Test at any angle, even upside down.
u Support "forged steel (Steel)" material, when using the D/DC impact device test "forged" sample, can read HB value directly, without the need for manual checking table.
u Wide measuring range. It can measure the hardness of all metallic materials. Direct display of hardness scales HRB, HRC, HRA, HV, HB, HS, HL and three types of strength values immediately.
u Seven impact devices are available for special application. Automatically identify the type of impact devices.
u Large capacity memory could store 600 groups (Relative to average times32~1 ) information including single measured value, mean value, testing data, impact direction, impact times, material and hardness scale etc.
u Upper and lower limit can be preset. It will alarm automatically when the result value exceeding the limit.
u Battery information indicates the rest capacity of the battery and the charge status.
u User calibration function.
u USB port with the PC humanity multi-functions data proceeding software.
u Original imported high speed thermal printer support the immediate printing function. It can save data permanently.
u NI-MH rechargeable battery as the power source. Charge circuit integrated inside the instrument. Continuous working period of no less than 200 hours (EL off and no printing).
u Auto power off to save energy.
u Industrialized housing design, sturdy, compact, portable, high reliability, suitable for harsh operating environment, vibration, shock and electromagnetic interference.
u Excellent after-sale service system for high quality products---two years’ guarantee and all life maintenance. Easy to buy and comfortable to use.
Technical Specifications:
|
Measuring Range |
HLD (170-960),HRC (17.9-69.5),HB (19-683),HV (80-1042),HS (30.6-102.6),HRA(59.1-88),HRB (13.5-101.7) |
|
Impact Directions |
Up, down, horizontal, slanting up, slanting down |
|
Measuring Materials |
Steel and cast steel, alloy tool steel, stainless steel, gray cast iron, nodular cast iron, cast aluminum alloy, copper zinc alloys (brass), an alloy of copper and tin, copper (bronze), forged steel |
|
Standards |
ASTM A956,DIN50156-1,GB/T17394-1998 |
|
Hardness Scales |
HL,HB,HRB,HRC,HRA,HV,HS. |
|
Tensile Strenght |
374 to 2652 N/m 2 |
|
Display |
128*64 digital matrix LCD |
|
Memory |
600 groups max.(relative to impact times 32~1) |
|
Work Voltage |
9V/500mA. |
|
Interface Port |
USB2.0 |
|
Dimensions |
210 x 85 x 45mm (host). |
|
Weight |
0.6kg (host). |
|
Continuous Working Period |
about 200hours(With backlight off, no printing) |
Main Application:
l Die cavity of molds
l Bearings and other parts
l Failure analysis of pressure vessel, steam generator and other equipment
l Heavy work piece
l The installed machinery and permanently assembled parts
l Testing surface of a small hollow space
l Material identification in the warehouse of metallic materials
l Rapid testing in large range and multi-measuring areas for large-scale work piece.
1. Delivery Packaging
Simulation Aninmatronic Costom Triceratops are covered with air bubble firm before put them into the wood en case, which not only has good shock absorption, impact resistance, heat sealing and also has theadvantages of nontoxic, odorless, moisture corrosion, good transparency ect.
2.Shipping & Delivery:
It depends on your requirement. We offer as many shipping options as possible, we have cooperated with some transpotation companies and shipping companies. If you need, we can transport products to our country port or even shipping to your country port.
Jinan Hensgrand Instrument Co., Ltd. was established in 2001, is specialized in developing and manufacturing of testing equipments. The machiens are designed to test mechanical property of metal, non-metal and composite materials.
Our main products are Hydraulic Universal Test Machine, Electronic Universal Test Machine, Compression Testing Machine, Spring Testing Machine, Impact Testing Machine, Torsion Testing Machine, Hardness Tester, Testing Machine Accessories, etc.
Our products sell well around the world, 90% products have CE, ISO, CNAS certifications
Lifelong after-sales service & maintenance;
Response within 24 hours for any problem;
Overseas training, installation is avaliable
Q:Are your company a trading one or a factory?
A:Factory + trade (integration),More than 20 years focusing on test instruments field,6 years exporting experience.
Q:After an order is placed, when to deliver?
A:Generally about 10-25days, If we have inventory, we can arrange shipment within 3 days.
Please be aware that our production lead times depend on specific items and item quantities.
Q:What about the warranty with after - sales services?
A:The testing machine is guaranteed for 16 months by HST,we can help you to repair
your problem controller freely,even it's not from our factory. After the warranty, the professional after-sale service team will provide perfect technical support and help guests solve problems encountered while using our product, handles guest
problems and complaints in a professional and timely.
Q:What about the product' services and quality?
A:Each instruments must be carried out 100% quality examination and test when shipping and delivery goods. Product use training, each of our product provide video training to show you how to install & operate. We can arrange engineer to train the operation of equipment to customer’s company when you need.
products are widely recognized and trusted by users.
