YES-100 100kN 200kN 300kN Digital Display Brick And Cement Compression Testing Machine 00kN Computerized Hydraulic Compression Flexural Testing Equipment
Contact: Claire Whatsapp/Wechat:86-15866781190 skype:hstbetty009
1. Main Application
Digital display compression testing machine mainly used for brick, cement, concrete construction material and other material compression resist testing.
Widely used in metallurgy, building materials, space flight and aviation, colleges and universities, R&D institution lines. The test operation and data processing meets standard requirements.
Feature:The test data is not only could displayed on LCD directly, but also could be displayed on computer screen.
2. Product description:
* Structure::mainly composed by main unit, oil source and measuring control system.
* Measuring control system:The machine adopts hydraulic loading, the electronic testing load. With digital display load, loading rate, keeping maximum load, overload protection and outage data keeping and other.
* Safety protection device:When the test force exceed the 3% of the maximum test force ,overload protection, the oil pump motor stop.
3. Main Technical Parameters
|
Model |
YES-100 |
YES-200 |
YES-300 |
|
Max. Load |
100kN |
200kN |
300kN |
|
Range of test force |
4-100kN |
8-200kN |
12-300kN |
|
Test space adjusting mode |
Block adjustment test space |
||
|
Control mode |
Manual control loading process |
||
|
Value repeatability error |
≤±1% |
||
|
Loading speed |
0.3KN/S~10KN/S |
||
|
Loading speed error |
±5% |
||
|
Piston stroke |
60mm |
||
|
Max compression space between two plates |
180 |
||
|
Working table size |
150mm×200mm |
||
|
Dimension |
1200x550x1400mm |
||
|
Power supply |
Main unit AC 380V±10%,control system 220V±10%, 0.75Kw |
||
