WDS 10kN 20kN 30kN 50kN 100kN 2Ton 5Ton10Ton Digital Electronic Universal Tensile Compressive Strength Test Machine
WDS 10kN 20kN 30kN 50kN 100kN 2Ton 5Ton10Ton Digital Electronic Universal Tensile Compressive Strength Test Machine
1. Application
WDS series digital display electronic universal testing machines are designed and manufactured according to ASTM,
ISO, DIN, GB and other international standards. Applicable for wide range of material for tensile, compression,
bending, shearing and low cycle test. It is for metal, rubber, plastic, spring, textile, and components testing. Widely used
in corresponding industries, research and development, test institutes and training centers etc.
2. Specification
|
Model |
WDS-5 |
WDS-10 |
WDS-20 |
WDS-30 |
WDS-50 |
WDS-100 |
|
|
Max. Load |
5kN 500kgf 1120lbf |
10kN 1000kgf 2240lbf |
20kN 2000kgf 4480lbf |
30kN 3000kgf 6720lbf |
50kN 5000kgf 11200lbf |
100kN 10000kgf 22400lbf |
|
|
Load accuracy |
≤±1% |
||||||
|
Load range |
2%-100% of full scale |
||||||
|
Disp. resolution |
0.01mm |
||||||
|
Test speed |
0.05-500mm/min |
0.05-300mm/min |
|||||
|
Tensile space |
750mm|30in |
650mm|25.6in |
650mm|25.6in |
||||
|
Comp. space |
750mm|30in |
650mm|25.6in |
650mm|25.6in |
||||
|
test width |
375mm |
400mm |
420mm |
||||
|
Dimension |
730×430×1700mm |
755×480×1780mm |
825×600×1950mm |
||||
|
Power supply |
220V, 1ph, 0.5kW |
220V, 1ph, 0.75kW |
220V, 1ph, 1kW |
||||
|
Weight (kg) |
250kg|550lb |
280kg|616lb |
350kg|770lb |
||||
