QGF-450 Automatic 20l Bottled Water Filling Machine 5 Gallon Production Line

Automatic decaper

Automatic cap pulling out machine is corollary production equipment specially designed for 5 gallons barrel drinking water filling and production line.

It is compact, high working efficiency and stable and reliable, high degree of automation, it is the machine electrical Trinity corollary equipment for 5 gallon barrel automatic water production line.

Automatic bottle exterior brushing machine:

Automatic barrel external brushing machine is special use for 5 gallon barreled drink water production line. Especially for mineral drink water, can effective remove the deposit and alga materials bring by mineralize on the bottom of the barrel, this machine is under bottom of the barrel, both rinsing the inside and outside the barrel, obvious improve the rinsing efficiency, reduce the second pollution by second manual brushing and fall the labor intensity.

Automatic bottle loader:

The empty barrel cleaned by inside and outside brushing machine sending through automatic loading system by transmission chain, loading barrel counter counting 2pcs barrels, blocking barrel cylinder action to stop feeding barrel, loading and pushing barrel action, and pushing barrel to barrel inverting frame reset, loading cylinder action to invert the barrel to level position and waiting for feeding barrel.

Washing part:

It has 2 rows and 9 steps washing
Water amount of filing: 6T/H
Consumption of water: consumption of water 1T/H(disinfection water reuse, water reuse one time)

Filling part:

Uploading and dropping barrels changed from 45 degree to translatory which is more stable.

Nozzle can insert into 10-15cm of the barrel in order to rinse little impurities down. Rinsing pump is separately controlled by different magnetic valves. Pump only work when there is barrel on that. It can avoid the mixture of different cleaning fluid.

Capping part:

Liquid level difference is controlled in 1cm.
Customers can choose to equip ABB/SEW motor, GRUNDFOS water pump, FESTO pneumatic component.

Light checker and steam heating shrink machine:

Inspection light is used for lighting when inspect whether exist sundries in barrel.

Heat shrinking machine is consist of water vessel and electric heat up, electric heat up to produce steam.

Automatic bag packing machine:

Automatic film feeding, feed, bag, sealing once completed, save manpower, improve efficiency, and realize unmanned operation docking production line. Teflon anti-stick coating alloy thermostatic sealing knife, sealing temperature is extremely sensitive and accurate, it can be arbitrarily set, sealing wire is not easy to crack, no edges, sealing more beautiful.

Leakage tester:

leakage checking machine is a professional machine to check leakage, after gas filling, pressure keeping, pressure testing, the machine will push damaged barrels out of conveyor.

QGF-450 5 gallon / 20liter water filling line with washing system

No.

Machine name

Model

Size(mm)

1

Automatic decapper

BG-1

850*650*1800

2

Exterior brushing machine

STNW-2

2210*1340*2140

3

QGF-450 main washing filling capping machine

QGF-450

5000*1580*2000

4

Light checker

DJ-1

300*700*1000

5

Shrinking machine

900*700*1200

6

Feeding conveyor belt

Plastic chain

7

Products outlet conveyor

SUS304

8

Roller conveyor

SUS304

9

Laser / ink jet printer

20W

340*220*100

Semi automatic 5 gallon / 20L PET bottle blow molding machine:

Semi automatic Blowing Machine for 90BPH-180BPH from 5 gallon bottle with one cavity, 5L bottle with 2 cavity can be also used in this blowing machine

RO System:

Besides Water filling machine, this RO system is very important in the whole water project, we prefer you supply water analysis report from your local inspection department.
This RO system we can make to match up with your water

filling machine from capacity from 500L/Hr to 50000L/hr.

We use GNP or CNP water pump, USA DOW or HYDRANAUTICS membrane, etc

Automatic shrink labeling machine for 5 gallon neck label:

Capacity: 50-100bottles/min can be chosen

Label material: PVC PET OPS, etc

Bottle material: PET PE PP Glass

Bottle Diameter: 28 ~ 120mm

Bottle Height: 15~320mm

Bottle shape: round, square, ellipse, rectangular

Label length: 30~250mm(max)

Label thickness: 0.03~0.13mm
