Home > Chemicals > Fiberglass Products > Other Fiberglass Products > Platform Gratings FRP Pultruded FRP Grates Walkway
Platform Gratings FRP Pultruded FRP Grates Walkway
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Distributor/Wholesaler
Year Established:
2000
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Heavy Duty Grate FRP/GRP Plastic Flooring Fire Resistant Fiberglass Pultruded GratingNegotiableMOQ: 1 -
Plastic Floor Grill Heavy Duty Fiberglass Grate Yellow Color FRP GratingNegotiableMOQ: 1
-
High Strength Composite Fiberglass Reinforced Anti Slip FRP Plastic Pultruded FRP GratingNegotiableMOQ: 1
-
GRP Floor Grating Walkway Plastic Frp Grate Tree Pool Protection Grid Car Wash Shop Drainage Channel Fiberglass GratingNegotiableMOQ: 1
-
38x38x38mm FRP GRP Grating High Strength Glass Fiber Grating PriceNegotiableMOQ: 1
Product Description
Platform Gratings FRP Pultruded FRP Grates Walkway
Pultruded FRP Grates offer higher strength characteristics and are ideally suited for heavier loads across longer spans than molded grating. The composite matrix of pultruded grating utilizes a higher fiberglass content to resin ratio resulting in a stiffer grate but with less corrosion resistance. Pultruded grating is a unidirectional structure and being an assembled product, allows for larger panel sizes for better utilization.
Load Bars: Pultruded grates are constructed of a series of independent load bars with either an "I" or "T" profile. "I" bars are typically used for industrial applications having a higher load capability
"T" bars are typically used for pedestrian applications having a wider walking surface.
Open area between the load bars can be as high as 60% or as small as 12% depending on your application and loading.
Load Bars: Pultruded grates are constructed of a series of independent load bars with either an "I" or "T" profile. "I" bars are typically used for industrial applications having a higher load capability
"T" bars are typically used for pedestrian applications having a wider walking surface.
Open area between the load bars can be as high as 60% or as small as 12% depending on your application and loading.
Resin Systems: available in two resin formulations both containing a fire retardant that offers an ASTM-E84 flame spread rating of 25 or less. ISOFR Isophthalic Polyester Fire Retardant Yellow / Dark Gray used for moderately corrosive environments VEFR Vinyl Ester Fire Retardant Yellow / Dark Gray used for highly corrosive environments
FRP Grating advantages
1. Corrosion resistant
2. High strength & light weight
3. Long service life
4. Fire retardant
5. Impact resistant
6. Nonconductive and thermal insulation
7. Non-magnetic electromagnetic transparency
8. Dimensional stability, Bright color
9. Low-maintenance
Pultruded frp grating pictures show
1. Corrosion resistant
2. High strength & light weight
3. Long service life
4. Fire retardant
5. Impact resistant
6. Nonconductive and thermal insulation
7. Non-magnetic electromagnetic transparency
8. Dimensional stability, Bright color
9. Low-maintenance
Pultruded frp grating pictures show
Specification
Type |
Height(mm) |
Top edge width (mm) |
Space between (mm) |
Clearance width(mm) |
Open area(%) |
Estimated weight kg/m2 |
I-4010 |
25 |
15 |
25 |
10 |
40 |
17.8 |
I-5010 |
25 |
15 |
30 |
15 |
50 |
15.1 |
I-6010A |
25 |
15 |
38 |
23 |
60 |
12.2 |
I-6010B |
25 |
8 |
19.8 |
11.8 |
60 |
13.7 |
I-4015 |
38 |
15 |
25 |
10 |
40 |
22 |
I-5015 |
38 |
15 |
30 |
15 |
50 |
19.1 |
I-6015 |
38 |
15 |
38 |
23 |
60 |
16.2 |
I-4012 |
30 |
15 |
25 |
10 |
40 |
19.1 |
I-5012 |
30 |
15 |
30 |
15 |
50 |
16.1 |
I-6012 |
30 |
15 |
38 |
23 |
60 |
13.1 |
I-40125 |
32 |
15 |
25 |
10 |
40 |
28.5 |
I-50125 |
32 |
15 |
30 |
15 |
50 |
24.2 |
I-60125 |
32 |
15 |
38 |
23 |
60 |
20.1 |
I-4020 |
50 |
15 |
25 |
10 |
40 |
28.5 |
I-5020 |
50 |
15 |
30 |
15 |
50 |
24.2 |
I-6020 |
50 |
15 |
38 |
23 |
60 |
20.1 |
Details Images
Fiberglass grating manufacturer FRP/GRP composite pultruded and molded gratings show
After-sales service
1.Provide install video if necessary and other install documents
2.Quality guarantee is 1 year.
3.If it was proved due to the quality problem,we will bear all cost for replace during quality guarantee time.
2.Quality guarantee is 1 year.
3.If it was proved due to the quality problem,we will bear all cost for replace during quality guarantee time.
Packing&Shipping
Related Products
1, high quanlity and best price Our company is Professional manufacturer ,
cheap price and guaranteed quality. we can do the test as your required , such as SGS, ISO and so on.
2, Accept customized,
Our company accept customized, if our catalog don't the size you need, is doesn't matter,
we can according your required to produce it.
3, Best service
Answering emails or solving questions timely. Delivery and update information on
time. Trust, good quality and service are the basic of long term business. I think you will satisfy with our service.
Give us your PO, let us cooperation for a long time.
cheap price and guaranteed quality. we can do the test as your required , such as SGS, ISO and so on.
2, Accept customized,
Our company accept customized, if our catalog don't the size you need, is doesn't matter,
we can according your required to produce it.
3, Best service
Answering emails or solving questions timely. Delivery and update information on
time. Trust, good quality and service are the basic of long term business. I think you will satisfy with our service.
Give us your PO, let us cooperation for a long time.
