Fibreglass Reinforce Plastic FRP GRP Pultruded Fiberglass Frp Tube Frp/Grp Pultrusion Profiles
FRP Pultruded Profile
Pultrusion is continuous process of manufacturing in which a specifically arranged pattern of resin rich reinforcement fibre and fabric is pulled through steel die to form profiles of consistent cross section of continuous length. Lanyu company has the ability of producing pultrude profiles as thin as 1.5 mm for radomes to sturdy sections up to 15 mm thickness. We also pultrude complicated shapes with outstanding accuracy such as fan blades, decks and custom purpose profiles.
Lanyu company has ability to produce pultruded FRP products using a range of reinforcement cores including glass rovings and carbon-fibers, chopped strand mats (CSM), Continuous filament mats (CFM) and Multiaxial fabrics. Through our in-house capability at LANYU we have a significant edge in terms of developing tailor-made reinforcement systems that optimally complement the different resin systems. Our experience in handling different matrix systems includes ISO, Ortho, Vinyl Ester, Epoxy Each of this resin systems have its own benefits in terms of cost effectiveness, chemical resistance and strength along different dimensions. We also use surface veils for achieving UV resistance and to give fine finish to the product.
Our mature pultrusion facility is matched with full equipped mechanical and chemical laboratories that help us perform all relevant tests for incoming raw materials and finished outputs. For very specialized tests, we have standing relationships with independent testing labs and academic institutions. Our quality team is well equipped to test using various international standards published by CTI, ASTM, ISO, EN, BS, DIN. We have highly qualified design and product development teams which routinely
work with customers to provide respective services, apart from supporting our own manufacturing and product development activities.
We also have well equipped fabrication facilities that use CNC machines integrated with CAD-CAM systems to provide fabricat ready-to-assemble products as per customer drawings. For products like x-arm bars and radomes, we also provide accessory components like end-caps and foam-inserts, as a part of fully assembled component/sub-system.
Lanyu company’s range of FRP pultruded products includes:
* Structural profiles such as square and round pipes, c-channels, angles, flats and rods
* Thin walled specialty profiles for Radomes and Fan-blades
* Heavy pultrusion upto 50 kg per meter for bridge decks and spans
* Speciality pultrusion for specific applications such as x-arm bars, customized railings, pultruded-gratings, square and round bars for electrical insulation and reinforcements
We also Accept customized
Pultrusion profile is a kind of compound materials which is formed by taking fiberglass as the reinforced material, and taking thermosetting resin as base, the fiberglass continuous roving enable the product to have the extremely high longitudinal strength, the fiberglass mat (continuous strand mat, knitted mat and so on) makes the product have the good transverse strength. The thermosetting resin base is usually the unsaturated polyester resin, the vinly resin, or the epoxy resin and the phenolic resin, the resin base enable the product to have the good anti-corrosion property, the different resin enables the product to be suitable for various corrosion environment, to add the ultraviolet inhibitor and fire retardant may enable the product to have the outstanding anti-aging property and the different rank anti-flammable property.
Feature
Corrosion-resistant
Light weight, high strength
Longevity of service, non-maintaining
Steady whole performance
Anti-ageing
Well insulated.
FRP Round tube |
||
Thickness |
2mm-10mm |
|
diameter |
19mm,35mm,40mm,50mm and so on |
|
customize |
yes |
|
FRP square tube
Thickness:2mm-15mm
Normal size: 19*19mm, 25*25mm, 38*38mm, 44*44mm, 50*50mm and so on
FRP rectangular tube
normal size: 60*28mm , 70*30mm and so on
Other FRP Pultrusion profiles
garden tube, kite pole, toys pole , mode polel,flag pole,bag rods,curtain pole, marking pole, tool handle, umbrella, and other
sport apparatuses as a supporting role
FAQ:
A: We are one 8 years manufacturer in hebei China our products have competitive price and quality guarantee.
Q: I am interested in your products, could I get sample for free?
A: We glad offer FREE samples for customer checking, customer just need afford its shipping cost,
A: 10-15days after receiving the deposit based on the MOQ. Normally, 25-30 days to finish the order for a 40ft container.
A: We have the quality control system ISO9001:2008, and we can do the SGS as your required
Q: Payment terms.
A: Basically, the payment terms are T/T, L/C at sight.Western Union, Paypal, Moneygram, Alipay, Credit card are acceptable for sample order.
