Description
• The SIM5215 series is a Dual-Band WCDMA and Tri-Band GSM/GPRS/EDGE module solution which supports WCDMA 384kbps for data transfer.
• With abundant application capability like embedded LUA script, TCP/ UDP/ FTP/ FTPS/ HTTP/ HTTPS/ SMTP/ POP3 and MMS, the module provides much flexibility and ease of integration for customer’s application. Its unique camera/video call feature shall add value to security solutions.

• It is ideal for a wide range of products including AMR, Gateway, Telematics, Tracking solution, Security solution and much more.

General features
* SIM5215A:Dual-Band UMTS/HSDPA 850/1900MHz
Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz
* SIM5215E:Dual-Band UMTS/HSDPA 900/2100MHz
Quad-Band GSM/GPRS/EDGE 850/900/1800MHz
* SIM5215J: Dual-Band UMTS/HSDPA 850(800)/2100MHz
Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz

* GPRS multi-slot class 12
* EDGE multi-slot Class 12
* WCDMA 3GPP release 5
* Output power
- UMTS 1900/850: 0.25W
- UMTS 2100/900: 0.25W
- GSM850/GSM900: 2W
- DCS1800: 1W
- PCS1900: 1W
* Control Via AT Commands
* Supply voltage range: 3.3V~ 4.2V
* Operation temperature: -30 °C to +80 °C
* Dimension: 36mm × 26mm × 4.7mm
* Weight: 7g

Specifications for Data transfer
* WCDMA
- Max.384Kbps(DL), Max.384Kbps(UL)
* EDGE
- Max. 236.8Kbps(DL),Max.118Kbps(UL)
* GPRS
- Max. 85.6Kbps(DL), Max.42.8Kbps(UL)
* CSD
- GSM data rate 14.4Kbps
- WCDMA data rate 57.6Kbps

Data transmission
WCDMA
- Downstream rate up to 384Kbps
- Uplink rate up to 384Kbps
* EDGE
- Downstream rate is up to 236.8Kbps
- Uplink rate up to 118Kbps
* GPRS
- Downstream rate is up to 85.6Kbps
- Uplink rate up to 42.8Kbps
* CSD
- GSM data transmission rate 14.4Kbps
- WCDMA data transmission rate 57.6Kbps

CSD
* Support GSM and WCDMA

Network Identification and Time Zone (NITZ)
* Support GSM and WCDMA

Video telephony features
* DTMF on H245
* Support standard 64kbps circuit domain video phone

Other features
* USB driver support: Microsoft Windows 2000/XP/Vista
* USB driver supports Linux 2.6.16
* Update firmware via USB
* MMS
*TCP/IP
* FTP/HTTP/SMTP/POP3
* FOTA
USB Audio

Specifications for SMS
* Point-to-point MO and MT
* Text and PDU mode

Interfaces
* USB2.0
* UART
* USIM card
* ADC
* Digital camera interface
* GPIO
* I2C
* Micro-SD card
