Home > Industrial Equipment & Components > Heater & Heat Exchanger > Heat Exchanger > Plate Heat Exchanger
Plate Heat Exchanger
US$ 1000 - 100000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
DGXT
Place of Origin:
China
Model Number:
AT
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
15 days
Related Products
-
Plate and Frame Heat ExchangerUS$ 1000 - 4000MOQ: 1 Piece -
NBR Gasket Ti Plate Heat Exchanger For Seawater Heating and CoolerUS$ 1000 - 4000MOQ: 1 Piece
-
China Titanium Plate Heat Exchanger ManufacturersUS$ 1000 - 4000MOQ: 1 Piece
-
Apv Gasketed Plate Heat Exchangers SanitaryUS$ 1000 - 4000MOQ: 1 Piece
-
Steel Carbon Frame Gasket SSI316 DGXT Good Quality Plate Heat ExchangerUS$ 1000 - 10000MOQ: 1 Piece
Brand Name
DGXT
Place of Origin
China
Model Number
AT
Certification
CE, UL
After-sales Service Provided
Overseas third-party support available
Warranty
2 year
Condition
New
Structure
Plate Heat Exchanger
Plate Heat Exchanger
| DGXT Plate heat exchanger | |||||
| Model | Connections | Flow Rate Max | Width | Height | Max surface |
| mm | ㎡ | mm | mm | ㎡ | |
| AT25-M | 25 | 8 | 140 | 380 | 1 |
| AT25-S | 25 | 8 | 200 | 621 | 1 |
| AT32-M | 32 | 14 | 180 | 490 | 3 |
| AT32-S | 32 | 14 | 200 | 896 | 5 |
| AT50-M | 50 | 45 | 320 | 930 | 37 |
| AT50-S | 50 | 45 | 300 | 994 | 40 |
| AT65-S | 65 | 72 | 430 | 1215 | 55 |
| AT100-M | 100 | 190 | 460 | 1084 | 100 |
| AT100-S | 100 | 190 | 480 | 1160 | 100 |
| AT100-S1 | 100 | 190 | 480 | 1755 | 200 |
| AT150-M | 150 | 390 | 650 | 1940 | 370 |
| AT150-S | 150 | 390 | 640 | 1450 | 370 |
| AT150-S1 | 150 | 390 | 640 | 1852 | 420 |
| AT200-M | 200 | 600 | 780 | 2260 | 410 |
| AT200-S | 200 | 650 | 790 | 1400 | 425 |
| AT200-S1 | 200 | 650 | 750 | 1700 | 425 |
| AT250-S | 250 | 650 | 750 | 2098 | 425 |
| AT250-S1 | 250 | 650 | 750 | 2500 | 425 |
| AT250-M | 250 | 900 | 920 | 2900 | 100 |
| AT300-M | 300 | 1400 | 1150 | 3100 | 1400 |
| AT300-S | 300 | 1400 | 970 | 1766 | 1400 |
| AT300-S1 | 300 | 1400 | 970 | 2176 | 1400 |
| AT350-S | 350 | 1400 | 1030 | 2806 | 1400 |
| AT350-S1 | 350 | 1400 | 1030 | 2176 | 1400 |
| AT500-S | 500 | 1800 | 1370 | 3560 | 1800 |
