RBL Concrete Detector Locator Scanner

RBL Concrete Detector Locator Scanner thumbnail-1
RBL Concrete Detector Locator Scanner thumbnail-2
RBL Concrete Detector Locator Scanner thumbnail-3
RBL Concrete Detector Locator Scanner thumbnail-4
RBL Concrete Detector Locator Scanner thumbnail-5
RBL Concrete Detector Locator Scanner photo-1
RBL Concrete Detector Locator Scanner photo-2
RBL Concrete Detector Locator Scanner photo-3
RBL Concrete Detector Locator Scanner photo-4
RBL Concrete Detector Locator Scanner photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
2017
Annual Export Value:
US$10 Million - US$50 Million
Contact Supplier Request Quote Chat Now
Cangzhou Lovely Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Product Description
1. The Rebar locator is a portable non-destructive testing instrument, which can be used for the detection of the construction quality of reinforced concrete structures.
2. It can measure the position of steel bars on the concrete surface and detect the thickness of the protective layer of the steel bars and the diameter of the steel bars.
3. ln addition, the position of magnets and conductors in concrete structures can also be detected, such as cables and plumbing pipes inside walls. The detection before construction can effectively avoid damage to these facilities and reduce accidents.
1.
Upgraded wireless cloud transmission function
2.
Adopt three anti-shell design, waterproof, dust-proof and shock-proof;
3.
Large screen high resolution LCD screen, the interface has Chinese prompts, more intuitive display content;
4.
Built-in large capacity memory card, storage capacity upgrade;
5.
USB transmission simulates the host computer as a U disk and reads data as easily as a U disk.
6.
Real-time display of protective layer thickness and steel signal image, minimum automatic locking;
7.
Dual-range operation mode can effectively ensure the detection accuracy and maximum detection depth;
8.
Automatic storage of test data, on-site statistical analysis results are provided immediately, which is convenient for guiding construction work;
9.
Professional data analysis software, so that your post-processing data and report generation work can be easily completed.
Technical Parameters
Product model
RBL
Applicable range of protective layer thickness(mm)
∅6mm~∅50mm
First range
6mm-90mm
Second range
6mm-200mm
Maximum allowable error of second range protective layer thickness
±1(mm)
6-80mm
±2(mm)
81-119mm
±4(mm)
120-200mm
Applicable scope of diameter estimation
∅6mm~∅32mm
Maximum error of diameter indication
±1 specifications
Section grid
Not support
Storage quantity
2000 components*1000 measuring points
Data transmission mode
USB, Wireless clod transport()options
Power supply mode
Lithium battery
Host parameters
Waterproof parameters:IP65
Screen size: 5 inches
Resolving power: 320x240
Volume: 195x140x45mm
Weight: 0.8kg
Powder supply
Large capacity lithium battery for more than 12 hours
Working environment requirements
Temperature:-10℃~40℃
Humidity: ＜90%RH
Other requirements
There is no corrosive gas in the air, No strong electromagnetic interface There should be no major shocks or shocks instruments to
avoid direct sunlight
Packing Specification
Material:Engineering plastics Volume: 420x140x335mm Weight: 5.5kg
Our Advantages
a. Package: Each product is individually packaged, providing instructions for chargers etc.
b. Security: No nuclear radiation and waste gas pollution, safe operation and use, environmental protection.
c. Operation: Simple operation, fast test speed, detection point only 35 seconds.

If you have any questions, please contact me without hesitation, welcome your inquiry! Price can be negotiated!
Our customer
Packing & Delivery
· Tianjin port or Qingdao Port deliver by sea and also can ship by air via express company
Company Profile
Cangzhou Lovely Technology Co., Ltd. is a professional manufacturer, specializing in Testing Equipment, Universal Testing Machine, Asphalt Tester, Test Molds, Soil Road and Lab Tester. We supply various type of products ..... We assure high quality to you.
All our products are made in China. Excellent quality with competitive price.
FAQ
Q1: Are you a factory or trading company?
A: We are a factory specializing in manufacturing soil, concrete, cement, aggregate , asphalt test equipment, etc.

Q2: Where is the loading port?
A: Tianjin port or Qingdao Port.

Q3: How to choose the Transportation Term?
A:Usually,we may according to your needs,we may choose the most reasonable freight,then to select for you.

Q4: What certificates do you have?
A: We have ISO 9001, CE, SGS.

Q5: Do you have an OEM service?
A: Yes. We can provide OEM services according to your requirements.

Q6: What are the payment terms?
A: T/T payment is preferred and other could be accepted, such as L/C, D/P, Western Union, PayPal etc. It is negotiable
