Product Usage and Features
HT225S Integrated Concrete test hammer
USAGE OVERVIEW GTJ-HT225S automatic integrated rebound hammer is used for non-destructive testing and evaluation of the compressive strength of hardened concrete in building structures. The parameters such as carbonization depth value, bounce angle, bounce test surface, and whether to pump or not can be set according to on-site inspection conditions. After the test is completed, the strength estimation result of the component can be given immediately.
Parameters
Model
GTJ-HT225
Sensor
MOS image sensor
Phone APP language
English/Chinese
Phone
5 inch Android system (optional)
Print function
Supports micro bluetooth printer (optional)


Data
Acquisition
Terminal
Input mode
Automatically record rebound value
Data processing
Automatic date vevision, calculation and analysis
Display mode
LCD
System capacity
200,000 Measuring points
Power mode
Rechargeable large capacity lithium battery
Wolume
123*55*25mm
Weight
200g


Mechanical Rebound Tester
Range of strength measurement
10~60 Mpa
Nominal kinetic energy
2.207J
Stiffness of spring strike
7.84N/cm
Hammer stroke
75mm
Indicative Consistency error
＜0.5
Calibrated rebound value of steel anvil
80±2
Volume
55*55*270mm
Weight
1.1KG
Working environment requirements
Temperature: -10℃ ~ +40℃ Humidity： ＜90%RH
Packing Specification
Material: engineering plastic
Volume:420*140*335mm
Weight: 4.8Kgs
Detailed Images
PRODUCT FEATURES:
◎Mobile APP control; ◎Instrument calibration can correct the deviation caused by temperature or environment; ◎Special computer software for data analysis can quickly generate test reports; ◎Portability: One-piece design, small size and easy to carry. ◎Digitalization: The rebound value is displayed in two forms of numbers and pointers, and the displayed value is consistent. ◎Convenience: Manage data according to components, estimate intensity, and record carbonization value on site. ◎Automation: Parameters such as the number of test areas, test direction, pouring surface, and pumping can be set and modified. After a component is tested and calculated, it is automatically transferred to the next test area according to the same parameters, eliminating the need for on-site manual recording and improving Detection efficiency and timeliness.
Application
Contact US
Cangzhou Lovely Technology Co., Ltd.

It is specialize in Nondestructive Test Instrument and Material Test Machine over 12 years. With advanced technologies and best customer service, our product has exported to over 100 countries and regions, which win favorable comments from customers worldwide. Our equipment is used throughout the world for testing soil, concrete, cement, asphalt and aggregate materials. This testing involves evaluations of materials, which are used in construction projects ranging from roads, bridges and tunnels to dams, earthworks, airports, railways, etc.

We adhere to the high standards of product quality, strict requirements, adopting the world-class production equipment, advanced management and production experience, developing the high-quality testing equipment.

We have has strong sales team and a comprehensive service process to serve end customers around the world.If you have any inquiry or concern,Sales and after service department will reply you within 24 hours.
Our Customers and patent certificate
Packing & Delivery
FAQ
Q1:Are you a factory or trading company? A:We are a factory specializing in testing equipment used for evaluating construction and civil engineering materials. We also deal with various related equipment based on customer's requirement. Q2:Where is the nearest loading port? A:Qingdao port or Tianjin port. Q3:What’s the MOQ of the product? A: One set. Q4:Did your factory pass the ISO 9001? A: YES. Q5:How long is the production cycle after ordering? A:Based on the order. Generally it is about 3-10 days. Q6:What is the payment method? A:T/T payment, West Union, L/C payment ect. Q7: Do you support customizing service? A: Yes, we could customize the out package, machine's color, Logo and Voltage as request. With more than 12 years' production experience. We would give you an excellent experience!
