Product Usage and Features
Concrete Ultrasonic Plus Velocity Tester
Usage:
Concrete Ultrasonic Plus Velocity Tester is used for testing both the surface and inner hardness of concrete with non nuclear method.
Concrete Ultrasonic Plus Velocity Tester/Ultrasonic Rebound Hammer is a comprehensive instrument for testing the strength of concrete. It can be used as an ordinary rebound tester or as an ultrasonic rebound comprehensive tester. It can measure the rebound value as well as the sound time and sound speed. It is suitable for non-destructive testing of common concrete compressive strength in various construction projects.
Parameters
Product name
U200 Ultrasonic pulse velocity tester
Type
GTJ-U200
Waterproof level
IP65
Screen Size
5 inches
Ultrasonic Frequency
50KHz
Stiffness of Spring Strike
785.0±40.0 (N/m)
Impact Length of Ram
75.0±0.3mm
Power Supply Mode
Large capacity lithium battery. Working time over 8 hours.
Working Environment
-10℃~40℃
Packing
Material: engineering plastic  Volume:420*140*335mm  Weight:5.5KGs
Detailed Images
PRODUCT FEATURE:
1. It adopts three anti- shell design waterproof, dustproof and shockproof;
2. Multi-function: Two methods to test the compressive strength of concrete: rebound method and ultrasonic rebound method. It can measure the rebound value, and can measure sound time and sound speed, which is simple and convenient.
3. High quality using imported sensors and advanced ARM processor, the test is fast and accurate, and the test results can be analyzed on site;
4. Easy to use: full English interface, with prompts, quick learning to conduct on-site testing;
5. Powerful: The instrument can store 4000 sets of data and record the test date at the same time, which is convenient for users to view and manage. The USB interface can quickly import data to the host computer for analysis and processing.

Application
